Aten CS82U KVM switch 2-port VGA/USB+PS2
|
-25% 52,45 EUR 70,04 EUR |
|
|
( 62,42 EUR incl. VAT ) ≈ £44.16 | ≈ $58.90 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 377969 |
| Mfg Part No: | CS82U |
| UPC/EAN: | 4710423777002 |
| Weight: | 0.97 kg |
Product information for Aten CS82U:
The CS82U PS/2-USB KVM switch is a desktop control unit that allows users to access two computers from a single KVM console. In addition, CS82U comes with ATEN's Video DynaSync technology, which eliminates boot-up display problems and optimizes resolution. Setup is fast and easy; simply plug cables into their appropriate ports. There is no software to configure, no installation routines, and no incompatibility problems. Since the CS82U intercepts keyboard input directly, it will work on multiple computing platforms.
| Design | |
| Product colour | Light grey |
| Housing material | Metal |
| Rack mounting | |
| LED indicators | |
| Push button | |
| Hot keys | |
| Display | |
| Built-in display | |
| Logistics data | |
| Master (outer) case net weight | 8.69 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 328 mm |
| Master (outer) case length | 497 mm |
| Master (outer) case height | 196 mm |
| Master (outer) case gross weight | 10.4 kg |
| Products per master (outer) case | 10 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Quick installation guide | |
| Manual | |
| Packaging data | |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 175 mm |
| Package weight | 981 g |
| Performance | |
| HD type | QXGA |
| Maximum resolution | 2048 x 1536 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 3,5,10,20 s |
| DDC2B support | |
| Ports & interfaces | |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 2 |
| Console ports | USB A, VGA (D-Sub) |
| Console USB ports quantity | 2 |
| DC-in jack | |
| Power | |
| Power source | DC |
| Input voltage | 5 V |
| Power consumption (typical) | 0.72 W |
| Weight & dimensions | |
| Width | 88 mm |
| Depth | 140 mm |
| Height | 55.5 mm |
| Weight | 869 g |
Questions & answers
What is the delivery time of Aten CS82U KVM switch 2-port VGA/USB+PS2?
The article Aten CS82U KVM switch 2-port VGA/USB+PS2 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten CS82U to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Aten CS82U KVM switch 2-port VGA/USB+PS2 always at the best possible price. We can give you a discount of 2% on Aten CS82U KVM switch 2-port VGA/USB+PS2 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
