Aten CS1732B-AT-G KVM switch VGA PS/2-USB audio USB-hub 2 ports

Your rating:
Average rating
product review for Aten CS1732B-AT-G KVM switch VGA PS/2-USB audio USB-hub 2 ports
( 4.7 / 5 ) 3 ratings
Aten CS1732B-AT-G
This image may differ from the desired article.
Aten CS1732B-AT-GAten CS1732B-AT-GAten CS1732B-AT-GAten CS1732B-AT-GAten CS1732B-AT-GAten CS1732B-AT-GAten CS1732B-AT-G
90,75 EUR
( 107,99 EUR incl. VAT )
≈ £75.59  |  ≈ $99.55
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Aten CS1732B-AT-G KVM switch VGA PS/2-USB audio USB-hub 2 ports
Datasheet:file_download Download
Lieske Part No.:887495
Mfg Part No: CS1732B-AT-G
UPC/EAN: 4710423775060
Weight:1.34 kg

Product information for Aten CS1732B-AT-G:

The Aten CS1732B-AT-G is a 2-port KVM switch with an integrated USB 2.0 hub, enabling control of two computers from a single console. The console consists of a keyboard, monitor, and mouse, connected to the respective computers via the switch. The device is designed as a desktop unit and features a metallic housing in black, providing a robust and compact design. Dimensions are 140 mm (width) × 88 mm (depth) × 55.5 mm (height), with a weight of 1.15 kg.

Applications
This switch is designed for use in office environments, server rooms, or by IT administrators who wish to control multiple systems from a single input console. It is particularly suitable for small and medium-sized businesses (SMBs) as well as home applications where efficient use of peripheral devices is required. Support for multiple operating systems, including Windows, Mac, and Sun, expands its range of applications.

Functions and Features in Detail
The CS1732B-AT-G offers four different methods for selecting computers: via front buttons, hotkey combinations, the On-Screen Display (OSD), and mouse click. The front buttons allow for quick, manual switching between connected computers. The multilingual OSD menu provides additional configuration options and status indicators. The hotkey function enables switching via predefined key combinations, which is especially useful for rapid transitions. Mouse control allows selection via a single click, making operation intuitive.

Technology Explained Simply
The switch supports a maximum resolution of 2048 x 1536 pixels at 60 Hz, complying with the QXGA standard. DDC2B support ensures that the computer's graphics card automatically adjusts the monitor resolution. The Video DynaSync™ technology stores the EDID (Extended Display Identification Data) of the connected monitor to ensure optimal image quality. Power supply is provided via an external power adapter with an input voltage of 5.3 V DC.

Compatibility and Accessories
The switch is equipped with two KVM ports, each supporting a VGA video connection (HD-15), a keyboard, and a mouse connection. The interfaces are dual, compatible with both PS/2 and USB keyboards and mice. Audio transmission is handled via 3.5 mm mini-phone stereo jacks, with two outputs (for speakers) and two inputs (for microphones) available per computer. The integrated USB 2.0 hub provides two Type-A ports, supporting additional USB devices such as printers or flash drives. The data rate is 480 Mb/s, complying with the USB 2.0 specification.

Installation and Mounting
Installation requires no additional software. Configuration is possible via front buttons, the OSD menu, or hotkeys. The delivery includes two KVM cable sets with a cable length of 1.2 m, enabling connections between the console and computers. Additionally, a firmware update cable, power adapter, two OSD/hotkey stickers, and a user manual are included. Connections are clearly labeled, and LED indicators on the front panel display the status of connected computers and USB connections.

Operational Advantages
The switch allows independent switching between KVM, USB, and audio signals, enabling flexible use of peripheral devices. Firmware is upgradable, ensuring long-term compatibility with new systems. The console, with mouse port emulation and bypass function, supports most mouse drivers and multifunction mice. The automatic scan function monitors all connected computers at a predefined interval (default: 5 seconds), enabling monitoring without manual intervention. Operating temperature ranges from 0 °C to 50 °C, with relative humidity during operation from 0 to 80 %, allowing use in standard office and server environments.

Design
Product colourBlack, Metallic
Housing materialMetal
Cable length1.2 m
LED indicatorsYes
Push buttonYes
Hot keysYes
Display
On Screen Display (OSD)Yes
Logistics data
Master (outer) case net weight11.5 kg
Harmonized System (HS) code85176200
Master (outer) case width335 mm
Master (outer) case length582 mm
Master (outer) case height195 mm
Master (outer) case gross weight14.2 kg
Products per master (outer) case10 pc(s)
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Packaging content
Cables includedKVM
Quick installation guideYes
ManualYes
Packaging data
Package width62 mm
Package depth283 mm
Package height173 mm
Package weight1.34 kg
Performance
HD typeQXGA
Maximum resolution2048 x 1536 pixels
Video bandwidth60 Hz
Scan interval1,255 s
DDC2B supportYes
Firmware upgradeableYes
Ports & interfaces
Number of computers controlled2
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeVGA
Console ports3.5mm headphone, 3.5mm mic
USB 2.0 Type-A hub ports quantity2
Headphone outputs4
Number of microphone inputs4
USB hubYes
Audio connectionsYes
DC-in jackYes
Power
Power sourceDC
Input voltage5.3 V
Power consumption (typical)2.5 W
System requirements
Windows operating systems supportedYes
Mac operating systems supportedYes
Technical data
Weight1.336kg
Height packaging0.173m
Packaging volume0.0030m³
Data rate480Mb/s
Max. resolution2048x1536
Video inputs per CPUVGA x1
Type 22-fold VGA KVM
USB specificationUSB 2.0
Width packaging0.062m
DesignDesktop
Number of CPU2
Type 1KVM switch
Length packaging0.283m
USB peripheralsYes
Front panel buttonsYes
Incl. KVM cablesetYes
Weight & dimensions
Width140 mm
Depth88 mm
Height55.5 mm
Weight1.15 kg


Product data sheet
Datasheet for Aten CS1732B-AT-G, EAN: 4710423775060
