Aten CL1000N
TFT drawer 19 1U, incl.TFT 19, Black, German
|
655,20 EUR |
|
|
( 779,69 EUR incl. VAT ) ≈ £547.09 | ≈ $734.48 plus delivery charges: 148,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 300727 |
| Mfg Part No: | CL1000N |
| UPC/EAN: | 4710469344121 |
| Weight: | 14.293 kg |
Further Racksystems 31+HE from AtenFurther products in category Racksystems 31+HE
All products of Aten
Product information for Aten CL1000N:
Aten TFT-drawer 19 1U, incl.TFT 19, Black, German,
- On order * Black, 48,3 cm ( 19 inch )LCD: 1280 x 1024 @ 75Hz, DDC2B,
TFT: 1xSPHD-15 jacks
Depth adjustable: 42-70cm,
incl.1xConsolenkabel to PC or KVM 1,8m {TFT: 1xSPHD-15 connectors,
KVM: 1xVGA (HDB 15 connector), 1xMaus / keyboard (USB connector),}
| Display | |
| Display diagonal | 48.3 cm (19") |
| Display | LCD |
| Keyboard | |
| Keyboard language | Swiss |
| Keyboard layout | QWERTZ |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Packaging content | |
| Cables included | AC, KVM |
| Manual | |
| Rack mount kit | |
| Power | |
| Power consumption (typical) | 24 W |
| Input current | 1 A |
| Technical data | |
| Fiber optic network | Without |
| Type 1 | KVM Display Console |
| Display diagonal | 19" |
| Keyboard layout | DE (German) |
| Number of CPU | 1 |
| Screen connectors per console | Without |
| Packaging volume | 0.0647m³ |
| Max. resolution | 1920x1200 / 60Hz |
| Periphery inputs per CPU | SPHD-15 female x1 (on USB, PS/2) |
| Design | Rack-Mount |
| Resolution integrated display | 1280x1024 |
| Weight | 14.293kg |
| Type 2 | VGA Single Rail |
| Height packaging | 0.135m |
| Audio per CPU | Without |
| Peripheral outputs per console | Without |
| Width packaging | 0.668m |
| Audio outputs per console | Without |
| Number of consoles | 1 (integrated) |
| Video outputs per console | Without |
| Length packaging | 0.718m |
| TP Network | Without |
| Video inputs per CPU | SPHD female (to VGA) x1 |
| USB peripherals | |
| Audio microphone | |
| Audio loudspeakers | |
| Technical details | |
| Product colour | Black |
| Operating relative humidity (H-H) | 0 - 80% |
| Maximum resolution | 1280 x 1024 pixels |
| Number of computers controlled | 1 |
| Rack capacity | 1U |
| Rack mounting | |
| LED indicators | |
| Weight & dimensions | |
| Width | 585.2 mm |
| Height | 44 mm |
| Depth | 483 mm |
| Weight | 11.1 kg |
Questions & answers
What is the delivery time of Aten CL1000N TFT drawer 19 1U, incl.TFT 19, Black, German?
The article Aten CL1000N TFT drawer 19 1U, incl.TFT 19, Black, German is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten CL1000N to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Aten CL1000N TFT drawer 19 1U, incl.TFT 19, Black, German always at the best possible price. We can give you a discount of 2% on Aten CL1000N TFT drawer 19 1U, incl.TFT 19, Black, German if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
