APC Symmetra LX 12kVA to 16kVA N+1 Ext. N+1 Ext. Run Tower 230V or 400V
|
26.220,00 EUR |
|
|
( 31.201,80 EUR incl. VAT ) ≈ £22,077.24 | ≈ $29,445.06 plus delivery charges |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 310092 |
| Mfg Part No: | SYA12K16IXR |
| UPC/EAN: | 0731304578314 |
| Weight: | 517 kg |
| Battery | |
| Battery replacement accessibility | End-user |
| Typical backup time at full load | 35.4 min |
| Typical backup time at half load | 77.4 min |
| Battery recharge time | 7.5 h |
| Replacement battery cartridge | SYBT5 |
| Certificates | |
| Compliance certificates | RoHS, WEEE |
| Certification | C-Tick; CE; GOST; VDE |
| Waste Electrical and Electronic Equipment (WEEE) compliance | |
| Design | |
| Product colour | Black, Silver |
| Features | |
| Output power capacity | 12 kVA |
| Output power | 8400 W |
| Waveform | Sine |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Single-phase input voltage supported | 240,220 V |
| Three-phase input voltage supported | 220,380,400,415 V |
| Emergency Power Off (EPO) | |
| Logistics data | |
| Customs product code (TARIC) | 8504409590 |
| Harmonized System (HS) code | 85078000 |
| Country of origin | Philippines |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Other features | |
| I/O ports | Pre-Installed SmartSlot Cards - AP9619 |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Interface | DB-9 RS-232, Smart-Slot |
| Output connections | (1) Hard Wire 3-wire (H N + G) |
| Input connection type | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 480 x 730 x 1520 mm |
| Nominal output voltage | 230 V |
| Output voltage note | Configurable for 220: 230 or 240 nominal output voltage |
| Networking features | Y |
| Output connection type | hard wire 3-wire (H N + E) for 1 zone(s) |
| Output voltage | 220 V |
| Mounting | front |
| Ports & interfaces | |
| AC outlet types | Hardwire |
| Power | |
| Input current (max) | 55 A |
| Technical details | |
| Packaging recycled materials | Recycled cardboard |
| Preferred mounting position | no preference |
| Sustainable packaging | |
| Take-back system | |
| Packaging without single use plastic | |
| Weight & dimensions | |
| Width | 483 mm |
| Depth | 726 mm |
| Height | 1516 mm |
| Weight | 488.6 kg |
Questions & answers
What is the delivery time of APC Symmetra LX 12kVA to 16kVA N+1 Ext. N+1 Ext. Run Tower 230V or 400V?
The article APC Symmetra LX 12kVA to 16kVA N+1 Ext. N+1 Ext. Run Tower 230V or 400V is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of APC SYA12K16IXR to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you APC Symmetra LX 12kVA to 16kVA N+1 Ext. N+1 Ext. Run Tower 230V or 400V always at the best possible price. We can give you a discount of 2% on APC Symmetra LX 12kVA to 16kVA N+1 Ext. N+1 Ext. Run Tower 230V or 400V if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
