APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks

Your rating:
Average rating
product review for APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks
( 4.5 / 5 ) 2 ratings
APC NBES0302
This image may differ from the desired article.
APC NBES0302APC NBES0302
94,99 EUR
( 113,04 EUR incl. VAT )
≈ £79.51  |  ≈ $104.39
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline
In Stock: >10 pieces
1x APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks
Datasheet:file_download Download
Lieske Part No.:793193
Mfg Part No: NBES0302
UPC/EAN: 0731304262954
Weight:0.32 kg
Type:ACCS

Product information for APC NBES0302:

The APC NetBotz door switch sensor NBES0302 is a universal sensor for monitoring access to a rack or room. It serves as a door contact sensor and enables detection of opening and closing operations on doors or covers of server racks, rooms or other enclosed units. The sensor is part of the NetBotz product family and is designed for integration into monitoring systems of the NetBotz 250A and 700 series. It is specifically designed for use with rack enclosures from APC or third-party manufacturers, allowing flexible adaptation to different infrastructures.

Applications

The sensor is suitable for monitoring access areas in data centres, server rooms, IT infrastructures or other enclosed rooms where physical security must be monitored. It can be mounted on doors of racks, enclosures or room doors to detect unauthorized openings or access. The application is particularly relevant in environments where continuous monitoring of physical access is required to prevent security incidents or unauthorized access.

Features and equipment in detail

The sensor features an RJ-45 connector, enabling connection to the NetBotz system. The maximum operating distance is 15.24 m, equivalent to 50 feet. This value is suitable for installation in larger rooms or with multiple rack units, as multiple sensors can be monitored via a single NetBotz device. The connection is made via an integrated cable that transmits status information (open/closed). The operating temperature ranges from 0 to 45 °C, enabling use in typical IT environments. The relative humidity during operation is up to 95 %, ensuring reliable operation even in humid rooms.

Technology explained simply

The sensor operates as a contact-operated switch, reporting the door status (open or closed) to the higher-level NetBotz system. The signal output occurs via the RJ-45 connector, directly integrated into the monitoring unit's network. The maximum distance of 15.24 m allows flexible placement of the sensor without requiring additional extension cables. The device dimensions are 111 mm (width) × 155 mm (depth) × 25 mm (height), making it compact and easy to install. The weight is 190 g, ensuring easy handling and installation. The packaging has dimensions of 232 mm × 164 mm × 48 mm and a package weight of 310 g.

Compatibility and accessories

The sensor is compatible with devices and pods of the NetBotz 250A and 700 series. It is designed for use with rack enclosures from APC or third-party manufacturers. The delivery includes cable ties, which can be used to secure the sensor or cable to the door or rack.

Installation and mounting

The use of cable ties allows secure mounting of the sensor to the respective surface. Installation requires connecting the RJ-45 connector to the NetBotz system. The maximum distance of 15.24 m allows flexible placement, provided the connection length is not exceeded.

Operational advantages

The sensor provides a reliable and simple way to monitor physical access to racks or rooms. Integration into existing NetBotz systems requires no additional hardware or software modifications. The maximum distance of 15.24 m enables monitoring of multiple points via a single device. The operating temperature and humidity are designed for typical IT environments, ensuring reliable operation under normal operating conditions. The included cable ties simplify installation and ensure proper securing of the sensor.

Environment and safety

The sensor is designed for indoor use. The operating temperature of 0 to 45 °C and relative humidity of 0 to 95 % cover most IT environments. Storage is possible at temperatures from -15 to 65 °C and relative humidity from 0 to 95 %, with a maximum storage altitude of 15,240 m. The product complies with the EU RoHS Directive and is free of substances of very high concern (SVHC) above the threshold, ensuring environmental compatibility and safety.

Operational conditions
Operating temperature (T-T)0 - 45 °C
Other features
Dimensions (WxDxH)111 x 155 x 25 mm
Packaging data
Package dimensions (WxDxH)232 x 164 x 48 mm
Package weight310 g
Security
Security featuresRJ-45
Maximum operating distance15.24 m
Weight & dimensions
Weight190 g


Product data sheet
Datasheet for APC NBES0302, EAN: 0731304262954

Questions & answers

What is the delivery time of APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks?

The article APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks is currently in stock

According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of APC NBES0302 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks always at the best possible price. We can give you a discount of 2% on APC NBES0302 NetBotz door switch sensor for rooms or 3rd Party racks if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
