APC APCRBC163 UPS replacement battery RBC163 for BGM1500, BGM1500B, BP1400, BR1500MS, BR1500MS2, BR1600SI content_copy

The APC replacement battery APCRBC163 is an original spare part for UPS systems of the Back-UPS series. As a lead-acid accumulator with a nominal voltage of 12 V and a capacity of 9.4 Ah, it serves to restore the original performance of uninterruptible power supplies. The battery is housed in a sealed battery cassette, enabling safe and compact integration into UPS devices. The housing color is black, and the dimensions are 302 mm height, 66 mm width, and 109 mm depth. The product weight is 5.85 kg.

Applications
The battery is specifically designed for use with various APC Back-UPS models, including BGM1500, BGM1500B, BP1400, BR1500MS, BR1500MS2, BR1600SI, BE 700 YIN, BE750BB-CN, BE800-IND, BK650I, BP500JPNP, BP650SX107, SC620X565, and SU620I. It serves as a replacement for worn-out or exchanged batteries to ensure the safety and reliability of power supply during power outages. The battery is not rack-mountable and is delivered as a single unit.

Functions and Equipment in Detail
The APCRBC163 is a lead-acid battery of the VRLA (Valve Regulated Lead Acid) type, designed for long service life. The manufacturer specifies a service life of 35 years, although this may vary under actual operating conditions. The battery is designed for use in stationary UPS systems and is used as a spare part to restore the original specifications of the UPS. The warranty is 24 months and includes repair or replacement.

Technology Explained Simply
The battery is based on lead-acid accumulator technology, in which chemical energy is converted into electrical energy. The VRLA technology ensures that the battery is maintenance-free and does not produce gas under normal use. The voltage of 12 V and the capacity of 9.4 Ah determine the runtime of the UPS during a power failure. The battery is not designed for mobile or industrial applications with high vibration or shock loads.

Compatibility and Accessories
The battery is delivered as a single unit without additional components. The packaging consists of recycled cardboard, and the packaging does not contain any single-use plastics. The packaging dimensions are 417 mm height, 185 mm width, and 180 mm depth, with a packaging weight of 6.3 kg.

Installation and Mounting
Installation is performed by inserting the battery cassette into the designated battery compartment of the UPS. Mounting requires no tools, as the battery is simply slid into the device. The battery is not designed for rack mounting. The installation instructions are included in the delivery scope according to manufacturer data.

Operational Advantages
The use of the original battery APCRBC163 ensures optimal performance and reliability of the UPS. The RoHS and REACH compliance ensures adherence to European environmental and safety regulations. The battery is designed for indoor use and is not intended for outdoor applications. Sustainability compliance is supported by the use of recycled cardboard for packaging. The service life of 35 years and the 2-year warranty provide long-term operational reliability.

Certifications and Environmental Aspects
The battery complies with the standards RoHS and REACH, ensuring the restriction of hazardous substances in electrical and electronic equipment. The CO₂ footprint over the entire life cycle is 41 kg CO₂ equivalents. The packaging is made of recycled cardboard, with no single-use plastics used. Product return is not provided according to manufacturer information.

Battery
Battery technology	Lead acid
Certificates
Compliance certificates	RoHS, REACH
Features
Battery life	35 year(s)
Product colour	Black
Logistics data
Customs product code (TARIC)	8507208090
Harmonized System (HS) code	85044095
Total carbon footprint (kg of CO2e)	41.26939141058102
Country of origin	Philippines
Packaging data
Package width	185 mm
Package height	417 mm
Package depth	180 mm
Package weight	6300 kg
Sustainability
Sustainability compliance
Technical details
Packaging recycled materials	Recycled cardboard
Sustainable packaging
Take-back system
Packaging without single use plastic
Weight & dimensions
Weight	5.85 kg
Width	66 mm
Height	302 mm
Depth	109 mm

---
