ALLNET Switch fully managed 26 Port Gigabit / 22x LAN / 4x SFP / fanless / 48,3 cm ( 19 inch ) / ALL-SG8626M

ALLNET Switch fully managed 26 port Gigabit / 24x LAN / 4x SFP / fanless / 48,3 cm ( 19 inch ) / ALL-SG8626M" Cost-effective 24 port Smart Managed Gigabit Layer-2 Switch +4x SFP MiniGbic slots without fan for desktop and 19 rack installation
Highlights: 26 Port Gigabit Layer2+ Switch Architecture Port 23/24 Combo Ports for TP or SFP (1G) and Port 25/26 SFP (1G) Slots Supports SFP DDM 48,3 cm ( 19 inch ) inch wall/table mounting angle possible The new ALLNET ALL-SG8626M switch provides a is the optimal basis for small and medium-sized workgroups with high network and data volumes and enables fast data transmission in the network.
Thanks to the fanless design, the ALL-SG8626M is also ideal for use in an office environment, as no annoying noise is generated + Fully Managed nd supports all necessary standards such as QoS, VLAN, Spanning Tree, IGMP Snooping and Link Layer Discovery Protocol. This ensures the highest performance
1588 time protocol for industrial computer networks.
The ALL-SG8626M is ideal for telecommunications and carriers -Ethernet applications and supports MEF service delivery and timing-over-packet solutions for IEEE 1588 and synchronous Ether
Strong Layer 2 features
The ALL-SG8626M Layer 2 Ethernet switch can provide advanced Layer 2 switch management features such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. By aggregating the supporting ports, the ALL-SG8626M enables the operation of a high-speed trunk group that has multiple ports and also supports fail-over.
Efficient and diverse management methods
For efficient management, the ALL-SG8626M is equipped with console, web and SNMP management interfaces.
With the integrated web-based management interface, it offers a user-friendly, platform-independent management and configuration option.
For text-based management, access is possible via Telnet and the console port.
For standards-based monitoring and management software, it provides an SNMPv3 connection that encrypts packet contents during each session for secure remote management.
Intelligent Switch with SFP-DDM Function
ALL-SG8626M supports the SFP-DDM (Digital Diagnostic Monitor) function, which enables the network administrator to easily monitor real-time parameters of the SFP transceivers, such as: B. optical output power, optical input power, temperature, laser bias voltage and transceiver supply voltage.
Technical data: Model ALL-SG8626M Copper Ports 22 0/100/1000BASE-T RJ45 auto-MDI/MDI-X ports Combo Ports 2-1000M BASE-T/BASE-X Combo ports Fiber Ports 2-100/1000BASE-X SFP interfaces, supports 00/1000Mbps dual mode Console Ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch Architecture Store-and-Forward Switch Fabric 52Gbps/non-blocking Throughput 38.69Mpps @64 bytes Address Table 8K entries Share Data Buffer 4.0 b Jumbo Frame 9600 Bytes SDRAM 1Gb Flash Memory 128Mb Flow Control IEEE 802.3x pause frame for full-duplex,Back pressure for half-duplex Reset Button > 2 ec: Factory default nd reset Power Supply 100~ 240V AC, 50/60Hz, 4A (max.) Power Consumption 12V, 45watts/1122 BTU LED Indicators Power: Green Solid on- power work normal, off- power disconnected
System: reen
Blink-work normally, solid on- soft work abnormal , fast Blink- soft upgrade
10/100/1000T RJ45 Interfaces (Port 1 to Port 24): 000 LNK/ACT (Green), 10/100 LNK/ACT (yellow)
Blink-port connected with data transmission Solid on-port connected without data transmission
100/1000Mbps SFP Interfaces (Port 25 to Port 28): reen
Blink- port connected with data transmission Solid on- port connected without data transmission EMC Surge Immunity: EC61000-4-5 ESD Protection: ESD IEC61000-4-2 : EFT IEC61000-4-4 Dimension 440x240x44.5mm Weight 3.2kg Working Temperature -10°C to 45°C Storage Temperature -20°C to 70°C MTBF 50,000hrs Layer 2 functions Port configuration Auto-negotiation Flow Control
Port Mirror: TX/RX/BOTH Many-to-1 monitor
CPU Mirror
Traffic statistics Link Aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk)
Algorith based on Source/Destination MAC
Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address
Dynamic MAC address management VLAN 4094 ctive VLANs 4094 ID
802.1Q Tag VLAN
Port VLAN
Protocol VLAN
MAC VLAN
Voice VLAN
802.1ad Q-in-Q tunneling
Private VLAN (Protected port)
GARP/GVRP ACL 256ACLs L2, L3 e L4
Time-based ACL
IP ACL
MAC ACL
MAC-IP ACL
User-Defined ACL
ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP)
802.1s Multiple Spanning Tree Protocol (MSTP)
Loop Guard
Root Guard
TC-BPDU Guard
BPDU Guard
BPDU Filter Ring Protection Static Routing IPv4 Unicast: Static Routing(Software Base) IPv6 Unicast: Static Routing(Software Base) IPV6 IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery
Internet Control Message Protocol (ICMP) version 6
TCPv6/ UDPv6
Ping6
Telnet(v6)
Http/Https
Interface IPV6
ACL IPV6
