ALLNET Switch unmanaged Layer2 8 Port? 8x 2.5GbE? Fanless? ALL-SG8008-2.5G

ALLNET Switch unmanaged Layer2 8 port • 8x 2.5GbE • Fanless • ALL-SG8008-2.5G Highlights: 8x multi-gigabit ports support up to 2.5 gigabit 4x speed (10M/100M/1G/2.5G). Increase network speeds by 2.5x without additional cabling costs. Plug and play, no complicated installation. The fanless design ensures completely silent operation. Flexible mounting options for placing the 2.5G switch in your environment Supports IEEE802.1x Flow Control Supports Jumbo Frame: 12K bytes Wall mounting possible Upgrade your existing CAT5A network infrastructure from the current 1GB to a max. 2.5GB network without having to replace your network cables. The 2.5 Gigabit Switch ALL-SG8008-2.5G is the perfect candidate if you want to expand the speed and performance of your network. It is up to 2.5 times faster than today's gigabit networks. As an out-of-the-box network speed upgrade, the ALL-SG8008-2.5G is an optimal solution for home or small office users who need more bandwidth for their network, e.g. for online gaming, multimedia streaming services or faster wireless network connections without the need for complex configuration.Mechanical Details: Technical Details: Items Specifications Model No. ALL-SG8008-2.5G Key Components 1. RTL9303+RTL8226Bx8Flash IC: MXIC 16M Byte DDR: 1G bits I/O ports 8 x 2.5G RJ45 Ethernet port LED Define PWR: Green LEDOff: power off or fail On: power on 1- 8 Port LED: Link/ACT:Off: port disconnected or link fail Green on: 2.5G bps connected Amber on: 100/1000Mbps connected Blinking: sending or receiving data HW feature IEEE802.3u100BASE-TX
IEEE802.3ab 1000BASE-T
IEEE802. 3bz 2.5G BASE-T
IEEE802.3az EEE
IEEE802.1x Flow control
MAC address Table: 16K Packet
buffer size: 12Mbit Jumbo Frame: 12K bytes
Forwarding Rate: 29.76Mpps (64-byte) Power Input External power supply Input: 90~264VAC /47~63Hz
Output: 12V/1.5A Dimension 270(W) x 146(D) x 32(H) mm FAN Design Fan-less Temperature Operating: 0 ~ 40°C
Storage: -40 ~ 70°C Humidity Operating: 10% ~ 90% RH (non-condensing)
Storage: 5% ~ 90% RH (non-condensing)
