ALLNET DS5-Pro Digital Signage RK3588 8GB/64GB Android 12/Linux Media Player

The most powerful digital signage multimedia player Rockchip RK3588, HDMI 2.1, WLAN AX 2.4 / 5GHz, 4K, USB 3.1 Our new multimedia player is a small, very powerful player with Android 12 or Linux. The player can be used as a TV box as well as a digital signage media player and mini PC. The RK3588 is currently the most powerful ARM processor and is on the level of an Intel Core i5 and up to 10x faster than an RK3399.
The connection to the Google app store gives you access to millions of apps.
The player can display up to 4K / 8K resolution with suitable displays. With its 4/8 / 16GB DDR4 RAM, the player has a very high performance in video playback and the memory runs less full than with the 2GB versions. The 32/64/128/256 GB hard drive offers enough space to store digital signage content offline.
A digital SPDIF audio output ensures the optimal cinema experience via a cinema sound system. It can be operated using an optional keyboard and mouse or the remote control included in delivery.
Models:
DS5Pro-4GB/32GB
DS5Pro-8GB/64GB
Package contents:
1 x 12V Power Supply
1 x HDMI® Cable
1 x User Manual + Color Box
1 x RK3588 Player
1 x Remote Control
Dimensions: 116x116x45mm
Comparison with RK3399 CPU:Processor Rockchip RK3588 Rockchip RK3399 Market (main) Single-board computer Single-board computer ISA ARMv8-A (64-bit) ARMv8-A (64-bit) Microarchitecture Cortex-A76, Cortex-A55 Cortex-A72, Cortex-A53 Family RK3500 RK3300 Part number(s), S-Spec RK3588 RK3399(K), RK3399 K Release date Q4 2021 Q1 2016 Lithography 8 nm LP 28 nm HKMG Cores 8 6 Threads 8 6 Base frequency 1.8 GHz 1.5 GHz Turbo frequency 2.4 GHz 2.0 GHz Energy cores 4x ARM Cortex-A55 @ 1.8 GHz 4x ARM Cortex-A53 @ 1.5 GHz High performance cores 4x ARM Cortex-A76 @ 2.4 GHz 2x ARM Cortex-A72 @ 2.0 GHz Cache memory 3 MB 1,512 MB Max memory capacity 32 GB 4 GB Memory types LPDDR4, LPDDR4X, LPDDR5 LPDDR3-1866,
LPDDR4 SDRAM Max PCIe lanes 4 4 TDP 12 W 7 W GPU integrated graphics ARM Mali-G610 MP4 ARM Mali-T860 MP4 GPU execution units 4 4 GPU shading units 64 64 GPU clock 600 MHz 600 MHz GPU FP32 floating point 610.6 GFLOPS 81.6 GFLOPS Socket SoC SoC Drystone MIPS 131,342 DMIPS 32,600 DMIPS AI accelerator AI Accelerator, NPU 3.0 - AI computing operations per seconds 6 TOPS - Crypto engine - AES 128/192/256, DES/3DES, SHA1/SHA256/MD5,
0, USB 2.0, USB 3.0, HDMI 2.1, PCIe 3.0, USB 2.0 Wi-Fi Wi-Fi 2.4GHz/5GHz - Bluetooth Bluetooth 4.2 - Audio PDM I2S, PCM, SPDIF PassMark CPU Mark 6,124 1,378 (Android 64-bit)
Geekbench 4 single core 2,423 1,144 (Android 64-bit)
Geekbench 4 multi-core 8,162 2,776 (Android)
Geekbench 5 single core 508 269 (Android)
Geekbench 5 multi-core 2,235 615 (SGEMM)
GFLOPS performance 72.1 GFLOPS 23.9 GFLOPS (Multi-core / watt performance)
Performance / watt ratio 680 pts / W 397 pts / W
