Allied Telesis AT-IE048-480-20 48V 480W SINGLE OUTPUT
|
248,74 EUR 249,47 EUR |
|
|
( 296,00 EUR incl. VAT ) ≈ £207.45 | ≈ $277.84 plus delivery charges: 55,00 € |
|
| Made to order · Expected to be available from 01.11.2026info_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1649442 |
| Mfg Part No: | AT-IE048-480-20 |
| UPC/EAN: | 4511427185417 |
| Weight: | 1.38 kg |
| Type: | CPNT |
Product information for Allied Telesis AT-IE048-480-20:
| Certificates | |
| Compliance certificates | RoHS, WEEE |
| Design | |
| Form factor | Tower |
| Housing material | Metal |
| Cooling type | Active |
| Product colour | White |
| LED indicators | Alarm, Status |
| Features | |
| Output power | 480 W |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 350 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (max) | 48 V |
| Maximum current | 15 A |
| Efficiency | 94% |
| Power factor | 0.98 |
| Power protection features | Over current, Over voltage, Overheating |
| Logistics data | |
| Export Control Classification Number (ECCN) | 5A992C |
| Harmonized System (HS) code | 8504.40.8500 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 20 - 90% |
| Other features | |
| Nominal output voltage | 48 V |
| Nominal input voltage | 90 - 264; 98 - 350 V |
| Ports & interfaces | |
| AC outlet types | Hardwire |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 117 mm |
| Height | 124 mm |
| Weight | 1.2 kg |
