Zebra ET45CB-101D2B0-A6 ET45 10 inch 5G WIFI6 SE4710 content_copy

The Zebra ET45CB-101D2B0-A6 is a mobile tablet of category TERM, specifically designed for use in demanding environments. It features a 25.6 cm (10.1 inch) display with a resolution of 1920 x 1200 pixels in WUXGA format, equipped with a brightness of 500 cd/m² and a capacitive touchscreen. The display is made of Gorilla Glass, ensuring high mechanical stability and scratch resistance. The device is based on a Qualcomm Snapdragon 695 processor with eight cores and is equipped with 8 GB LPDDR4x SDRAM RAM and 128 GB flash memory. The operating system is Android 11, pre-configured with Google Mobile Services (GMS).

Applications
This tablet is suitable for mobile applications in logistics, retail, and industrial environments where a robust, portable, and network-capable workstation is required. The IP65 protection rating makes it dust- and splash-proof, allowing use even under harsh conditions outdoors or in production environments. The operating temperature range of -20 to 50 °C and storage temperature range of -40 to 70 °C extend its usability in climatically variable environments.

Functions and Equipment in Detail
The device features a rear camera with 13 megapixels, equipped with a flash, and a front camera with 5 megapixels. Integrated sensors include an ambient light sensor, gyroscope, and electronic compass, ensuring precise motion detection and orientation. Two built-in speakers and two microphones support communication and voice recording. Positioning is achieved via A-GPS, GLONASS, BeiDou, and Galileo, enabling global and precise location tracking.

Technology Explained Simply
The Qualcomm Snapdragon 695 processor offers balanced performance for mobile applications, suitable for both office and field operations. The 8 GB RAM and 128 GB flash memory provide sufficient capacity for the operating system, applications, and data. The battery capacity is 7600 mAh (29.41 Wh), ensuring sufficient runtime for mobile use. Power supply is via a lithium-ion battery, included in the device.

Compatibility and Accessories
The tablet supports 5G mobile networks, Wi-Fi 6 (802.11ax), and Bluetooth 5.1. WLAN standards include 802.11a, b, g, n, ac, and ax. The SIM card type is NanoSIM. A USB 2.0 Type-C port enables connection to external devices and data transfer.

Mounting and Installation
The device is designed as a mobile tablet and is typically handheld. Installation is performed via the pre-configured Android 11 operating system, which is immediately usable after power on and off.

Operational Advantages
The combination of robust construction IP65), long-lasting battery, modern networking technology (5G, Wi-Fi 6), and a powerful processor makes the Zebra ET45 a reliable tool for mobile work processes. Integrated GPS and camera functions support applications such as inventory management, delivery tracking, and mobile data processing. The use of Google Mobile Services enables access to a wide range of applications from the Google Play Store.

Audio
Number of built-in speakers	2
Number of microphones	2
Battery
Battery technology	Lithium-Ion (Li-Ion)
Battery capacity	7600 mAh
Battery voltage	3.87 V
Battery included
Camera
Rear camera type	Single camera
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP
Rear camera flash
Front camera
Design
Device type	Mobile tablet
Form factor	Slate
Product colour	Black
Display
Display diagonal	25.6 cm (10.1")
Display resolution	1920 x 1200 pixels
Display brightness	500 cd/m²
Display glass type	Gorilla Glass
Touchscreen type	Capacitive
HD type	WUXGA
Endurance
International Protection (IP) code	IP65
Memory
Internal memory	8 GB
Internal memory type	LPDDR4x-SDRAM
Network
Mobile network generation	5G
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
SIM card type	NanoSIM
Mobile network connection
Bluetooth
Operational conditions
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95%
Performance
Assisted GPS (A-GPS)
GLONASS
BeiDou
Galileo
Position location
Ports & interfaces
USB 2.0 Type-C ports quantity	1
Processor
Processor manufacturer	Qualcomm
Processor family	Snapdragon
Processor model	695
Processor cores	8
Sensors
Ambient light sensor
Gyroscope
Electronic compass
Software
Platform	Android
Operating system installed	Android 11
Storage
Internal storage capacity	128 GB
Storage media	Flash
Weight & dimensions
Width	257.9 mm
Depth	11.4 mm
Height	162.9 mm
Weight	690 g

---
