Walther-Werke 6H10102LA plastic hanging combination 16 A RCD-A CEE outlet 4 Schuko connection up to 6 mm²
|
601,42 EUR 601,82 EUR |
|
|
( 715,69 EUR incl. VAT ) ≈ £503.39 | ≈ $670.58 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 1058437 |
|---|---|
| Mfg Part No: | 6H10102LA |
| UPC/EAN: | 4015609525263 |
| Weight: | 0.123 kg |
| Type: | 6H10102LA |
Product information for Walther-Werke 6H10102LA:
in accordance with IEC 61439-part 1 and 3
Housing (6H1) made of silicone and halogen-free PC/ABS
Color: RAL 1016/9005 -sulphur yellow/jet black-
with 2 hanging eyes
with handle hook at the bottom
with a transparent cover that snaps into place at the top
Protection class II
Protection type: IP44
Size approx.: 450 x 136 x 221mm / HBT
Connection:
1 cable gland M25 at the top
1 connection up to 6qmm 5P
outlets/fuse:
1 residual current device (RCD) 4P 40A/30mA -A-
1 CEE mounting box straight 16A 5P 400V 6h
4 earthed sockets 16A 3P 230V
1 compressed air connection
with internal thread at the top and bottom 1/2 inch
compressed air class 5
operating pressure < 16 bar
Hanging socket combination according to DIN EN 61439:
individually tested
, wired ready for connection,
rated current: 16A
