WAGO 751-9402 Compact Controller 100,8DI 8DIO 2AI 2AIO 2NI/PT 2RS485,2xETHERNET
|
740,60 EUR |
|
|
( 881,31 EUR incl. VAT ) ≈ £619.88 | ≈ $813.92 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 614455 |
|---|---|
| Mfg Part No: | 751-9402 |
| UPC/EAN: | 4066966618754 |
| Weight: | 0.123 kg |
| Type: | 751-9402 |
Product information for WAGO 751-9402:
Applications
The Compact Controller 100 is used in applications requiring a compact, powerful control system with high I/O density. Typical use cases include controlling production lines, packaging machines, conveyor systems, or small automation systems in manufacturing. The integrated SD card enables storage of configurations, log data, or firmware updates, simplifying maintenance and diagnostics. Support for RS485 interfaces allows connection to serial devices, such as frequency converters or industrial sensors.
Functions and Equipment in Detail
The device features 8 digital inputs (DI), 8 digital input/output (DIO), 2 analog inputs (AI), 2 analog input/output (AIO), 2 network interfaces (NI/PT), and 2 RS485 interfaces. The DIO and AIO interfaces enable bidirectional communication, allowing the device to function as both a sensor and actuator interface. The two Ethernet ports enable connection to local networks or higher-level control systems, although the exact network functionality (e.g., VLAN, QoS) is not specified.
Technology Explained Simply
The control system is based on an integrated processor that processes input data and generates corresponding output signals. Digital inputs capture binary signals from switches, limit switches, or sensors, while analog inputs capture continuous values, such as from temperature or pressure sensors. Outputs control actuators such as relays, valves, or motors. The RS485 interfaces enable serial communication using a data transmission standard widely used in industry. The SD card serves as an external storage medium for configuration data, log files, or firmware updates, facilitating maintenance and diagnostics.
Compatibility and Accessories
The Compact Controller 100 can be combined with various accessories to extend connection options. These include spring terminals and spring clamps with a pitch of 3.5 mm, such as the 2091-1104 spring terminal with handle plate, 4-pole, the 2091-1102 spring clamp, 2-pole with handle plate, or the 2091-1122 spring terminal, 2-pole. These enable secure and quick cable connections. Additionally, release aids such as the 2092-1630 release aid for Picomax are available, facilitating cable disconnection.
Mounting and Installation
Mounting is done on standard DIN rails, enabling easy integration into existing enclosures. Connections are made via spring clamps, ensuring quick and secure connections. Installation requires wiring of input and output signals and network connection via the Ethernet ports. The SD card is directly integrated into the device and can be replaced if necessary.
Advantages in Operation
The Compact Controller 100 offers high I/O density in a compact form factor, reducing space requirements in enclosures. The integrated SD card enables flexible data management, and support for multiple interfaces (Ethernet, RS485) simplifies integration into existing systems. The use of spring clamps ensures reliable and fast wiring, reducing installation time.
| General | |
| Number of digital inputs | 8 |
| Number of digital inputs/outputs | 8 |
| Number of analogue inputs | 2 |
| Number of analog inputs/outputs | 2 |
| Number of network interfaces | 2 |
| Number of RS485 interfaces | 2 |
| Number of Ethernet ports | 2 |
