Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs
|
57,84 EUR |
|||||||||||
|
( 68,83 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 1336523 | ||||||||||
| Mfg Part No: | 021-1BF00 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for VIPA 021-1BF00:
8x DI
DC 24 V
The SM 021 digital input module (021-1BF00) is an ideal solution for capturing digital input signals in automation systems. It provides 8 digital inputs (DI) with a nominal voltage of DC 24 V, making it perfect for applications where fast and reliable signal acquisition is crucial. The module features a green status LED for each channel to display the state of each input, as well as a green LED for module status and a red LED to indicate module errors. The ability to connect two-wire BEROs adds flexibility to its application. Its compact design allows for easy installation in both horizontal and vertical configurations.
Technical Data:
Order No.:- 021-1BF00
Type:
- SM 021 - Digital Input
Module ID:
- 0005 9FC1
General Information:
- Note:-
Features:
- 8x DI
- DC 24 V
Current Consumption/Power Loss:
- Current consumption from backplane bus:65 mA
- Power loss:0.9 W
Technical Data Digital Inputs:
- Number of inputs:8
- Cable length, shielded:1000 m
- Cable length, unshielded:600 m
- Rated load voltage:-
- Current consumption from load voltage L+ (without load):-
- Rated value DC:20.4...28.8 V
- Input voltage for signal "0 cm ( 0 inch ):DC 0...5 V
- Input voltage for signal "2,5 cm ( 1 inch ):DC 15...28.8 V
- Input voltage hysteresis:-
- Signal logic input:Sinking input
- Frequency range:-
- Input resistance:-
- Input capacitance:-
- Input current for signal "2,5 cm ( 1 inch ):3 mA
- Connection of two-wire BEROs possible:Yes
- Max. permissible BERO quiescent current:0.5 mA
- Input delay of 0 cm ( 0 inch ) to "1:3 ms
- Input delay of 2,5 cm ( 1 inch ) to "0:3 ms
- Number of simultaneously usable inputs in horizontal configuration:8
- Number of simultaneously usable inputs in vertical configuration:8
- Input characteristic curve:IEC 61131-2, type 1
- Initial data size:8 Bit
Status Information, Alarms, Diagnostics:
- Status display:Green LED per channel
- Interrupts:No
- Process alarm:No
- Diagnostic interrupt:No
- Diagnostic functions:No
- Diagnostics information read-out:None
- Module state:Green LED
- Module error display:Red LED
Type: 021-1BF00
Questions & answers
What is the delivery time of Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs?
The article Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of VIPA 021-1BF00 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs always at the best possible price. We can give you a discount of 2% on Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 pieces of Vipa 021-1BF00 SM 021 Digital input 0005 9FC1 8 inputs we can offer you a price of 56,97 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
