Vertiv (Knürr) MIRACEL 2.0 LAN H2000 B800 T600

* Order-related, cannot be canceled*, – With fixed 19” installation at the front and rear for installations in accordance with IEC 297-3. – Installation of slide-in rails, drawers, pull-out shelves and cable management – Cable entry via base and cover. – Cable entry on the cover, rear cover installation or removal possible after wiring. – Dissipation of heat loss via raised roof – Door – opening angle 160° with internal hinges for maneuvering space – Front 123 mm. Load capacity – 8000 N static. Protection class - IP 20. Tests - Earthing according to VDE 0100 T 540. - IP test according to EN 60529. Material / surface - Base frame extruded aluminum. – Corner connector made of die-cast aluminum, blank. – Cladding parts made of galvanized sheet steel, powder-coated structure – Doors made of sheet steel, powder-coated structure, glass filling on the front with 4 mm toughened safety glass – 19” profiles, 1.5 mm sheet steel, galvanized Color – Visible surfaces and cladding parts RAL 7035 light gray. Scope of delivery – 1 base frame. – 4 x 19” perforated sheet steel profiles including HE marking. For a cabinet depth of 600mm, only 2x 48,3 cm ( 19 inch ) profiles – 2 x side panels with quick-release fasteners. – 1 x raised lid with cable entry (three-part sliding plates, can also be opened completely) at the rear. – 1 x front door, single-leaf, toughened safety glass, with handle and holder for locking cylinder. – 1 x rear door, single-leaf, sheet steel, with handle and holder for lock cylinder. – 1 x base with ventilation slots at the front and back, filter mat can be retrofitted – 4 x leveling feet .
