* Order-related, non-cancellable*, – Perforated front doors with single locking. – Perforated rear doors with single locking. – Special 48,3 cm ( 19 inch ) server profiles to accommodate all commercially available 48,3 cm ( 19 inch ) servers. – Installations according to IEC 297-3. – Standard cable entry with fixed cable duct on the right. – Possible cable entry on the left and right via the cover and base by subsequently converting the cable ducts. – Safe separation of the individual bays through fixed bulkhead floors. – With side air partitions on the left and right front, each with 1 U opening for holding various components. – Doors with handle and holder for locking cylinder. – Adjustment of the 48,3 cm ( 19 inch ) profiles in 50 mm increments. Marshalling space – 80 mm at the front. Load capacity – 25 kg per HE stationary. – E.g.: 15 HE x 25 kg = 375 kg load for one bay. Protection class –
IP 20. Tests – Earthing according to VDE 0100 T 450. - IP test according to DIN 40 050 / IEC 529. Flow cross section - Perforation 83% - Base frame extruded aluminum, bright. - Corner connectors made of die-cast aluminum. Bulkheads made of galvanized sheet steel. - 48,3 cm ( 19 inch ) profiles, 2.0 mm sheet steel, galvanized. – Galvanized depth struts. Color – visible surfaces of the trim parts RAL 7021 black gray. Scope of delivery – 1 base frame. – 4 48,3 cm ( 19 inch ) server profiles with hole grid, sheet steel with HE marking per bay. – 1 cover including covers for cable inlet on the left and right. – 1 base including covers for cable inlet on the right, left open for cable duct? Cable entry. – 2 bulkhead shelves. – 3 perforated front and rear doors. – Air partition at the front with covered 1 U cutout. Delivery condition – Note – Order mounting adapter for 48,3 cm ( 19 inch ) server profile for mounting Knürr accessories. – Side bulkheads must be ordered separately. – Locking cylinders must be ordered separately.
Please note...
This article has over-weight and though needs to be transported by a forwarding agency. Please mind, that the calculation of the delivery charges in the shopping cart disregard this aspect.
Though, there will be corresponding surcharges after you send us your order.
Questions & answers
What is the delivery time of Vertiv (Knürr) DCM Colo-Rack H2200 W800 T1100 ST 3-fold, 3x 15U bays, with side panels, W800/H2200/D1100mm, RAL7021?
The article Vertiv (Knürr) DCM Colo-Rack H2200 W800 T1100 ST 3-fold, 3x 15U bays, with side panels, W800/H2200/D1100mm, RAL7021 is currently
not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 11 working days.
The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time.
Just send us an inquiry about the desired quantity of Vertiv 011430028003 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Vertiv (Knürr) DCM Colo-Rack H2200 W800 T1100 ST 3-fold, 3x 15U bays, with side panels, W800/H2200/D1100mm, RAL7021 always at the best possible price. We can give you a discount of 2% on
Vertiv (Knürr) DCM Colo-Rack H2200 W800 T1100 ST 3-fold, 3x 15U bays, with side panels, W800/H2200/D1100mm, RAL7021 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
