VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission
|
101,76 EUR |
|||||||||||
|
incl. 18,21 EUR copper surcharge ( 121,09 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Sales unit: 50 meters | |||||||||||
| Lieske Part No.: | 130979 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 10175906 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for VDE-Kabel 10175906:
with VDE / HAR-approval
Application:
The use of ölbeständiggen DIN VDE and HAR control line
H05VV5-F is required in many areas of industry. The type fin-
det application, eg in tool and packaging engineering,
materials handling and automation technology in the automotive industry in
CNC machining centers.
Building:
Conductor: Bare copper, fine wireaccording to VDE 0295 cl 5
Insulation: PVC
Core identification: VDE 0293
JZ = black cores with consecutive run-
printed numbers and the green-yellow
protective conductor
OZ = black cores with
consecutive numbers without
protective conductor stranded in layers
Sheath: special PVC blend
increased oil resistance
Color: gray
Specifications:
Rated voltage: 300/500 VTest voltage: 3000 V
Temperature range: - 5 ° C + 70 ° C (dynamic)
-40 ° C +70 ° C (non-moving)
bending radius: 12.5 x cable diameter
(Flexible use)
Flame resistance according to VDE 0472 T. 804
Category B (= IEC 332-1)
Oil resistance: very good to DIN VDE 0281 part 1
of cores x cross-section mm ² Rated: 3 G 1.50
Outer diameter approx: 8.3
Cu index (kg / m%): 4.32
approx Weight (kg / m%): 11.5 Type: MEGA H05VV5-F 3G1, 5
Item: 50 MTR
Type: MEGA-H05VV5-F 3G1,5
The item price shown refers to 50 meters VDE-Kabel 10175906
Questions & answers
What is the delivery time of VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission?
The article VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of VDE-Kabel 10175906 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission always at the best possible price. We can give you a discount of 2% on VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 meters of VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission we can offer you a price of 98,00 EUR per piece. The more you buy, the cheaper the article will be.
You can also send us a price proposal for your desired quantity of VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission via the form price proposal. Enter your name, contact details, price and quantity you need. Our sales team will then send you a good quotation immediately.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
VDE-Kabel 10175906 H05VV5-F 3G1, 5 mm ² 50m ring, UL, CSA, VDE / HAR, SEV - Admission is offered by us in a sales unit of 50 meters If you need a larger quantity, you can contact us at any time. We will make a special offer for you
