Ubiquiti UniFi Enterprise Access Hub / PoE / AUX / EAH-8
|
848,96 EUR 879,83 EUR |
|
|
( 1.010,26 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 2027588 |
|---|---|
| Mfg Part No: | EAH-8 |
| Weight: | 9.8 kg |
Product information for Ubiquiti EAH-8:
(8+8) Inputs for exit request devices and door position sensors
(8) PoE ports for access readers
(4) AUX ports for bells, sirens or door openers
(1) Battery backup input (32-48V)
Technical Specifications Mechanical Dimensions 379 x 355 x 105 mm (15 x 14 x 10,4 cm ( 4,1 inch )) Weight Unit: 9.1 kg (20 lb)
Bracket: 624 g (1.4 lb) Housing Material SGCC case with PC cover Mounting Material SGCC wall mount plate Hardware Network Interface (10) 10/100/1000 Base-T Power Method Universal input, 100-240 VAC, ~4.4 A max., 50/60 Hz,
32-48 VDC, Lead acid battery Power supply AC/DC, internal Max. power consumption 240W PoE interface (8) PoE (pins 1, 2+ 3, 6-) Voltage range PoE mode 44-57 VDC Total available PoE 60W Max. PoE wattage per port 15.4W Button (1) Factory reset LEDs System: white/blue
Output relay: solid white
Ethernet: flashing white Digital input (8) Prompt device inputs
(8) Door position sensor inputs
(1) Emergency dry output relay (8) Lock terminals (12V or dry)
(4) AUX terminals for advanced setup (chime/siren/door opener) Powered output relay Lock: 12 VDC, 1A/ dry
Aux: Dry only Recommend max. cable length 18 AWG
UACC cable DoorLockRelay length 20
AWG length 22
AWG length 24
AWG Length UA-Lock-Electric
(400mA) 100 m
(328 ft) 66 m
(217 ft) 42 m
(138 ft) 25 m
(82 ft) UA-Lock-Magnetic-270kg
(800mA) 46 m
(151 ft) 30 m
(98 ft) 20 m
(66 ft) 12 m
(29 ft) UA-Lock-Magnetic-540kg
(500mA) 80 m
(262 ft) 51 m
(167 ft) 32 m
(105 ft) 20 m
(66 ft) Other Locks
(1A) 36 m
(118 ft) 24 m
(79 ft) 15 m
(49 ft) 9 m
(30 ft) Operating Environment Indoor Use Only Operating Temperature 0 to 40 °C (32 to 104 °F) Operating Humidity 5 to 95% non-condensing Certifications CE, FCC, IC
Questions & answers
What is the delivery time of Ubiquiti UniFi Enterprise Access Hub / PoE / AUX / EAH-8?
The article Ubiquiti UniFi Enterprise Access Hub / PoE / AUX / EAH-8 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 11 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Ubiquiti EAH-8 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Ubiquiti UniFi Enterprise Access Hub / PoE / AUX / EAH-8 always at the best possible price. We can give you a discount of 2% on Ubiquiti UniFi Enterprise Access Hub / PoE / AUX / EAH-8 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
