Insert with screw connection EPIC® H-BE 16 SS DR, Insert with screw connection pin, Number of contacts: 16+PE, Size: 16B, 500 V AC rms / DC according to IEC, 16 A according to UL/CSA, For cross-section (min./max.): 0.5mm² - 2.5mm², Contacts included, Polycarbonate, Areas of application: For transmitting control signals to actuators and servo drives, Suitable for wiring inside control cabinets, Typical areas of application are stage, lighting and lifting technology, For connecting the power supply to devices and machines in various applications, Benefits: Inserts from the EPIC® H-BE series are considered classics in industry and are ideal for use with higher voltages and currents, Wide variety of suitable housing variations, UL certification according to technical data enables the product to be used in North America, VDE-tested quality, Made of robust polycarbonate (flammability class V-0 according to UL94 test method for the flammability of plastics), Article available with or without wire protection The wire protection enables the direct connection of stranded wires without wire end ferrules, In the EPIC® H-BE series, inserts of different connection types can be combined with one another as required within the same size (screw, crimp, cage clamp or push-in), Service-friendly screw connection allows assembly without special tools, Also certified according to UL 508 A / UL 2237 for applications in control cabinets, Can be used in rail vehicles in accordance with standards (testing of fire behavior according to DIN EN 45545-2:2016-02, requirement sets R22 and R23, hazard levels HL1, HL2 and HL3)
Type: H-BE 16SS
The item price shown refers to 5 pieces U.I. Lapp 10194000
Questions & answers
What is the delivery time of U.I. Lapp 10194000 LAPP pin insert H-BE 16 SS ?
The article U.I. Lapp 10194000 LAPP pin insert H-BE 16 SS is currently
in stock
According to our experience the article is ready for dispatch within 52 working days.
The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time.
Just send us an inquiry about the desired quantity of U.I. Lapp 10194000 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you U.I. Lapp 10194000 LAPP pin insert H-BE 16 SS always at the best possible price. We can give you a discount of 2% on
U.I. Lapp 10194000 LAPP pin insert H-BE 16 SS if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
U.I. Lapp 10194000 LAPP pin insert H-BE 16 SS is offered by us in a sales unit of 5 pieces If you need a larger quantity, you can contact us at any time. We will make a special offer for you
