TERRA PC BUSINESS 7000 content_copy

General
Processor model: Intel Core Ultra 7 (Series 2) 265 / 30 MB Intel Smart Cache, max. 5.3 GHz
Operating system: Windows 11 Pro
Software
Pre-installed software: 1 month trial version for new Microsoft® 365 user
Processor
Processor family: Intel® Core™ Ultra 7 Processor
Processor cores: 20-Core
Processor socket: FCLGA1851 Socket
Number of processors: 1
Memory
Internal memory: 16 GB
Memory layout (slots x size): 2 x 8 GB
Maximum internal memory: 256 GB
Memory clock speed: PC4800 MHz
Internal memory type: DDR5 SDRAM
Memory slots: 4 pc(s)
Memory form factor: DIMM, 288-PIN
Storage
Total storage capacity: 1 TB
HDD interface: 1x M.2 2280 PCIe 5.0 x4/x2, 1x M.2 2280 PCIe 4.0 x4/x2, 4x SATA 6Gb/s (RAID 0, 1, 5, 10 Support only for SATA)
RAID levels: RAID 0, 1, 5, 10 (No M.2 NVMe RAID support)
SSD interface: PCIe (NVMe)
Number of storage drives supported: 1x M.2 PCIe 5.0 x4/x2
1x M.2 PCIe 4.0 x4/x2
4x SATA 6Gb/s
Storage media: SSD - M.2
Performance
Series: Business
Noise level: 22,7 dB (Idle-Mode)
Audio output channels: 7.1 Channel Surround
Motherboard chipset: Intel B860 Express
Audio system: Realtek Audio CODEC High Definition Audio
Design
Chassis type: Mid tower
Certification: Assemblierung nach ISO9001 in Deutschland
Kompatibilität: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
Produkt entspricht den Kriterien des RAL UZ 78 (Blauer Engel)
Keyboard form factor: TERRA Keyboard
Keyboard
Connectivity technology: Wired
Device interface: USB
Technical details
Localization: German
Packaging content
Included Accessories: Quick Start Guide, Powercord EU
Expansion slots
Expansion slots: 1x PCIe 5.0 x16 slot
2x PCIe 4.0 x1 slots
Weight & dimensions
Altura: 43.5 cm
Ancho: 18 cm
Profundidad: 42 cm
Peso: 8 kg
Other features
Number of drive bays: 1 von vorne zugänglich - 13.3 cm (13,3 cm ( 5,2 inch ))
1 von vorne zugänglich - 8.9 cm (8,9 cm ( 3,5 inch ))
2 intern - 8.9 cm (8,9 cm ( 3,5 inch )/ 6,3 cm ( 2,5 inch ) mit Adapter)
1 intern - 6.4 cm ( 6,3 cm ( 2,5 inch ) )
Interface: Front: 2x USB 3.2 Gen 1, MIC, Mine-Out
Back: 1x PS/2
1x HDMI / 2x DP
1x USB 3.2 Gen 2 Typ A / 2x USB 3.2 Gen 1 / 3x USB 2.0/1.1
1x RJ-45 port
3x Audio
Compatible operating systems: Windows 10, Windows 11
Motherboard manufacturer: Gigabyte B860M DS3H
Cooling type: Active
Compliance industry standards: This appliance is classified as a Class B information technology equipment (ITE) and is intended primarily for use in residential and office environments. The CE mark confirms conformity with the following EU directives: (1) EMC Directive 2004/108/EC Electromagnetic Compatibility (2) Low Voltage Directive 2006/95/EC Electrical equipment designed for use within certain voltage limits.
Special features: TPM 2.0
Secure Boot
Windows Autopilot ready
2x USB 3.2 Gen1 Typ A + Audio in Front
Mouse
Mouse included: Terra Mouse Corded
Graphics
On-board graphics adapter memory: Dynamisch GB
On-board graphics adapter maximum resolution: 1x HDMI, max. 4096x2160@60 Hz
2x DP, max. 3840x2160@144 Hz
Graphics card: Intel Graphics
On-board graphics card model: Intel Graphics
On-board graphics card: integrated
Graphics adapter ports: 1x HDMI, 2xDP (Display Port)
Unterstützt Triple-Monitoring
Power
Power source: ATX power supply. Meets 80-plus Bronce
Eligible for regular business use max. 60h/ week
Energy efficiency (Workload 10 %/ 20 %/ 50 % / 100 %): 82 %/ 82 % / 85 % / 82 %
Power consumption (standby): Ø 2.25 Watt (S3 Mode. Suspend to RAM. WOL aktiviert)
0.24 Watt Soft off (S5 Mode) W
Maximum input power: 350 W
Nominal power: Ø 24,85 Watt Idle-Mode
Ø 93,76 kWh pro Jahr (TEC = Typical Energy Consumption)
Weitere Informationen zur Leistungsaufnahme siehe http://www.wortmann.de/green und/ oder in den Quicklinks zu diesem Produkt (sofern vorhanden)
AC adapter input voltage: AC 230V ( 50 Hz )
Operational conditions
Operating temperature (T-T): +23°C ±5°C
Recommended humidity operating range: 10 - 80% (non-condensing)
Network
Ethernet LAN: Netzwerkadapter - integriert
LAN controller: Realtek® 2.5GbE LAN
Data link protocols: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Optical drive
Optical drive type: optional
Input device
Movement detection technology: Optical
Device interface: USB

Audio
Audio system	High Definition Audio
Design
Chassis type	Midi Tower
Product colour	Black
Cooling type	Active
Display
Display included
Expansion slots
PCI Express x1 (Gen 4.x) slots	2
PCI Express x16 (Gen 5.x) slots	1
Expansion slots	1x PCIe 5.0 x16 slot ¦ 2x PCIe 4.0 x1 slots
Features
Motherboard manufacturer	Gigabyte B860M DS3H
Graphics
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® Graphics
On-board graphics card model	Intel® Graphics
Number of external displays supported	3
Resolution description	1x HDMI, max. 4096x2160@60 Hz ¦ 2x DP, max. 3840x2160@144 Hz
Graphics card HDMI ports quantity	1
Graphics card DisplayPorts quantity	2
Discrete graphics card
On-board graphics card
Keyboard
Keyboard connectivity	Wired
Keyboard language	German
Memory
Internal memory	16 GB
Maximum internal memory	256 GB
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	2 x 8 GB
Memory slots	4x DIMM
Memory clock speed	4800 MHz
Network
Ethernet LAN data rates	100,1000,2500 Mbit/s
Ethernet LAN
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, WebNN, Windows ML
NPU performance up to	13 TOPs
Sparsity support
Windows Studio effects support
Operational conditions
Operating temperature (T-T)	18 - 28 °C
Operating relative humidity (H-H)	10 - 80%
Other features
Locale	German
Packaging content
Mouse connectivity	Wired
Cables included	AC
Mouse included
Keyboard included
Manual
Performance
Market positioning	Business
Product type	PC
Trusted Platform Module (TPM) version	2.0
Audio output channels	7.1 channels
Sound pressure level	22.7 dB
Trusted Platform Module (TPM)
Ports & interfaces
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
DisplayPorts quantity	2
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
PS/2 ports quantity	1
Number of front audio ports	2
Number of rear audio ports	3
Line-out
Microphone in
Power
Power supply	350 W
Power supply input voltage	230 V
Power supply input frequency	50 Hz
Power consumption (typical)	24.85 W
Power consumption (standby)	2.25 W
Power consumption (off)	0.24 W
80 PLUS certification	80 PLUS Bronze
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 7
Processor generation	Intel Core Ultra (Series 2)
Processor model	265
Processor cores	20
Processor threads	20
Processor boost frequency	5.3 GHz
Performance cores	8
Efficient cores	12
Performance-core Max Turbo Frequency	5.2 GHz
Efficient-core Max Turbo Frequency	4.6 GHz
Performance-core base frequency	2.4 GHz
Efficient-core base frequency	1.8 GHz
Processor cache	30 MB
Processor cache type	Smart Cache
Number of processors installed	1
Processor socket	LGA 1851 (Socket V1)
Processor base power	65 W
Maximum turbo power	182 W
Software
Operating system installed	Windows 11 Pro
Compatible operating systems	Windows 10, Windows 11
Storage
Total storage capacity	1 TB
Storage media	SSD
Number of storage drives installed	1
Number of storage drives supported	6
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express
SSD form factor	M.2
RAID levels	5, 1, 0, 10
Optical drive type
NVMe
RAID support
Weight & dimensions
Width	180 mm
Depth	420 mm
Height	435 mm
Weight	8 kg

---
