Telegärtner H02050A0158
Gru.platte f., Splice (stacking) f.BasisV content_copy

Housing with 2 cable entries each for M20 and M25, front panel, 1 cable screw connection M25 for 9-13 mm, 1 cable screw connection M20 for 5-9 mm, 2 blind plugs each for M20 and M25, splice cassette with integrated splice holders for max. 24 fibers, cover for splice cassette, couplings and pigtails see table, fully assembled. If pigtails are supplied, splice protection for crimp splices system Telekom and labeling strips are included. Patch panels for fiber optic cables are suitable for dividing multi-core fiber optic cables into single cores, either as a distribution frame or with a closed housing to accommodate splice cassettes. They can be installed in all standardized 19' distribution cabinets and can be precisely tailored to the respective requirements thanks to the modular design. Housings and front panels are available up to 3 HE. All accessories such as screw connections, splice cassettes, fiber optic couplings and fastening parts can be combined as required and can also be supplied assembled on request. There is also a selection of fully assembled patch panels equipped with useful accessories that are suitable for most applications. The 19' patch panel series includes the ECONOMY V, BASIS V, BASIS eco, PROFI V, PROFI Plus, PROFI T versions as well as the modular fiber optic distribution system. A 10' ECONOMY version distributor completes the range. Base plate for splice cassette for BASIS V 3 HE stackable
