Siglent SSG3021X
Signal Generator / The SSG3021X signal generator offers normal analog modulation such as AM, FM and PM.
|
1.967,25 EUR |
|
|
( 2.341,03 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1153621 |
|---|---|
| Mfg Part No: | SSG3021X |
| Weight: | 7 kg |
Product information for Siglent SSG3021X:
FeaturesFrequency up to 2.1 GHz/3.2 GHz 0.01 Hz resolution of frequency setting Level output from -110 dBm to +13 dBm Maximum level up to +20 dBm (typ.) Phase noise: -110 dBc/Hz at 1 GHz, 20 kHz offset (typ.) Level accuracy =0.7 dB (typ.) Provides analog AM, FM and PM modulation with internal, external or Int+Ext source Pulse modulation, on/off ratio =70 dBc Pulse train generator (option) External IQ modulation with SDG6000X as baseband IQ signal USB power meter measurement kit 5-inch TFT capacitive touch screen, mouse and keyboard supported Web browser remote control on PC and mobile devices Standard interfaces include USB host, USB device (USB TMC), LAN (VXI-11, Socket, Telnet). Optional interface: GPIB Technical data Model comparison
SSG3021X
SSG3032X
SSG3021X-IQE
SSG3032X-IQE Frequency range 9 kHz~2.1 GHz 9kHz~3.2GHz 9 kHz~2.1 GHz 9kHz~3.2GHz Amplitude resolution 0.01dB 0.01dB 0.01dB 0.01dB Phase noise -110 dBc/Hz @1 GHz, offset 20 kHz (typ.) -110 dBc/Hz @1 GHz, offset 20 kHz (typ.) -110 dBc/Hz @1 GHz, offset 20 kHz (typ.) -110 dBc/Hz @1 GHz, offset 20 kHz (typ.) External I/Q modulation No No Yes Yes
Questions & answers
What is the delivery time of Siglent SSG3021X Signal Generator / The SSG3021X signal generator offers normal analog modulation such as AM, FM and PM.?
The article Siglent SSG3021X Signal Generator / The SSG3021X signal generator offers normal analog modulation such as AM, FM and PM. is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 11 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Siglent SSG3021X to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Siglent SSG3021X Signal Generator / The SSG3021X signal generator offers normal analog modulation such as AM, FM and PM. always at the best possible price. We can give you a discount of 2% on Siglent SSG3021X Signal Generator / The SSG3021X signal generator offers normal analog modulation such as AM, FM and PM. if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
