Siglent SPS5164X
DC laboratory power supply / The SPS5164X is a DC laboratory power supply with two channels and has a maximum output power of 720W.
|
on request |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1156188 |
|---|---|
| Mfg Part No: | SPS5164X |
| Weight: | 5.5 kg |
Product information for Siglent SPS5164X:
SPS5041X 1 Channel, 40V/30A/360W 2.4 inch OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 30mA Voltage: 0.1% ± 20mV Current: 0.1% ± 40mA
SPS5042X 1 Channel, 40V/60A/720W 2.4 inch OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 60mA Voltage: 0.1% ± 20mV Current: 0.1% ± 70mA
SPS5043X 1 channel, 40V/90A/1080W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 100mA Voltage: 0.1% ± 20mV Current: 0.1% ± 100mA
SPS5044X 2 channels, 40V/30A/720W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 30 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 40 mA
SPS5045X 3 channels, 40 V/30 A/1080 W 2.4 inch OLED screen 1 mV/1 mA Voltage: 0.1% ± 10 mV Current: 0.1% ± 30 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 40 mA
SPS5051X 1 channel, 50 V/10 A/180 W 2.4 inch OLED screen 1 mV/1 mA Voltage: 0.1% ± 10 mV Current: 0.1% ± 10 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 20 mA
SPS5081X 1 channel, 80V/15A/360W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 10mA Voltage: 0.1% ± 20mV Current: 0.1% ± 20mA
SPS5082X 1 channel, 80V/30A/720W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 10mV Current: 0.1% ± 30mA Voltage: 0.1% ± 20mV Current: 0.1% ± 40mA
SPS5083X 1 channel, 80V/45A/1080W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 10 mV Current: 0.1% ± 40 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 50 mA
SPS5084X 2 channels, 80 V/15 A/720 W 2.4 inch OLED screen 1mV/1mA Voltage: 0.1% ± 10 mV Current: 0.1% ± 10 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 20 mA
SPS5085X 3 channels, 80 V/15 A/1080 W 2.4 inch OLED screen 1mV/1mA Voltage: 0.1% ± 10 mV Current: 0.1% ± 10 mA Voltage: 0.1% ± 20 mV Current: 0.1% ± 20 mA
SPS5161X 1 channel, 160 V / 7.5 A / 360 W 2.4 inch OLED screen 1 mV / 1 mA Voltage: 0.1% ± 100 mV Current: 0.1% ± 5 mA Voltage: 0.1% ± 100 mV Current: 0.1% ± 5 mA
SPS5162X 1 channel, 160 V / 15 A / 720 W 2.4 inch OLED screen 1 mV / 1 mA Voltage: 0.1% ± 100 mV Current: 0.1% ± 15 mA Voltage: 0.1% ± 100 mV Current: 0.1% ± 15 mA
SPS5163X 1 channel, 160 V/22.5A/1080W 2.4-inch OLED screen 1mV/1mA Voltage: 0.1% ± 100mV Current: 0.1% ± 20mA Voltage: 0.1% ± 100mV Current: 0.1% ± 20mA
SPS5164X 2 channels, 160V/7.5A/720W 6,1 cm ( 2,4 inch ) OLED screen 1mV/1mA Voltage: 0.1% ± 100mV Current: 0.1% ± 5mA Voltage: 0.1% ± 100mV Current: 0.1% ± 5mA SPS5165X 3 channels, 160V/7.5A/1080W 2.4\dlashOLED screen 1mV/1mA Voltage: 0.1% ± 100mV Current: 0.1% ± 5mA Voltage: 0.1% ± 100mV Current: 0.1% ± 5mA
Questions & answers
What is the delivery time of Siglent SPS5164X DC laboratory power supply / The SPS5164X is a DC laboratory power supply with two channels and has a maximum output power of 720W.?
The article Siglent SPS5164X DC laboratory power supply / The SPS5164X is a DC laboratory power supply with two channels and has a maximum output power of 720W. is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 11 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Siglent SPS5164X to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Siglent SPS5164X DC laboratory power supply / The SPS5164X is a DC laboratory power supply with two channels and has a maximum output power of 720W. always at the best possible price. We can give you a discount of 2% on Siglent SPS5164X DC laboratory power supply / The SPS5164X is a DC laboratory power supply with two channels and has a maximum output power of 720W. if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
