Siglent SDS1102CML
+ 100MHz dual-channel oscilloscope

The SDS1102CML+ is a general-purpose dual-channel digital oscilloscope with 100MHz bandwidth. It includes 2Mpts memory depth to ensure accurate waveform resolution and capture longer signal lengths. Thanks to the 7-inch TFT LCD screen (800*480), there is ample screen space to better see and analyze the waveform details. Besides 1GSa/s sampling rate, the SDS1000CML+ supports 32 parameter measurements and general mathematical operations to speed up complex/repetitive measurements.Features models with 150MHz, 100MHz, 70MHz and 50MHz bandwidth. Real-time sampling rate up to 1GSa/s, equivalent time sampling rate up to 50GSa/s. Memory depth up to 2Mpts. Trigger types: edge, pulse, video, slope, alternate. Waveform calculation functions: +, -, *, /, FFT. 6 digital frequency counter. Supports multi-language display and embedded online help. Screen saver from 1 minute to 5 hours. Digital filter and waveform recording function. 7 inch TFT-LCD display with 800*480 resolution. Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11), Pass/Fail. Shortcut memory function key. Technical data Device specification
SDS1102CML+
SDS1052DL+ Bandwidth 100 MHz 50 MHz Channels 2CH +Ext 2CH +Ext Real-time sampling rate 1 GSa/s 500 MSa/s Memory depth 32 K 2 Mpts Rise time 3.5 ns 7 ns Input impedance 1MO?17pF 1MO?17pF Time base range 2.5ns/div-50s/div 10ns/div-50s/div Vertical sensitivity 2mV-10V/div 2mV-10V/div Vertical resolution 8 bit 8 bit Trigger source CH1, CH2, Ext, Ext/5, AC Line CH1, CH2, Ext, Ext/5, AC Line Trigger types Edge, Pulse, Video, Slope, Alternative Edge, Pulse, Video, Slope, Alternative Interfaces USB Host, USB Device, LAN, Pass/Fail USB Host, USB Device, LAN, Pass/Fail, RS232
