Siemens 3UF70001AB000 Basic Unit 1 SIMOCODE C 3UF7000-1AB00-0

Basic unit SIMOCODE pro C, PROFIBUS DP interface 12 MBit/s, RS-485, 4I/3O freely parameterizable, US: 24 V DC, input for thermistor connection, monostable relay outputs Motor management system SIMOCODE pro C for comprehensive protection, monitoring and control functions for asynchronous motors as well as detailed operating, service and diagnostic data for process control systems and controllers via the most common field bus systems. The compact motor management system with PROFIBUS DP interface for direct and reversing starters or control of a circuit breaker works independently of the automation system. It supplies detailed operating, service and diagnostic data - always and everywhere. Worldwide approvals (e.g. IEC and UL/CSA) are also available for potentially explosive applications (ATEX or IEC Ex). Use with IE3/IE4 motors is supported. The SIMOCODE ES (TIA Portal) software is available for configuring, commissioning, operating and diagnosing SIMOCODE pro. With the SIMOCODE pro block library for SIMATIC PCS 7, SIMOCODE pro can be easily integrated into the SIMATIC PCS 7 process control system.The SIMOCODE pro C basic units are available with DC 24 V or AC/DC 110-240 V control supply voltage.At least one current measuring module and a suitable 3UF793 connecting cable are required for operation. These and an optional operator panel are available separately.A step into the future with SIMOCODE pro.
Type: 3UF7000-1AB00-0
