Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10
|
225,46 EUR |
|||||||||||
|
incl. 4,74 EUR copper surcharge ( 268,30 EUR incl. VAT ) ≈ £188.71 | ≈ $247.78 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 2 workdaysinfo_outline | |||||||||||
| In Stock: 3 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 570679 | ||||||||||
| Mfg Part No: | 3RV20214PA10 | ||||||||||
| UPC/EAN: | 4011209716261 | ||||||||||
| Weight: | 0.387 kg | ||||||||||
| Type: | 3RV2021-4PA10 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Siemens 3RV20214PA10:
Applications
The power switch is suitable for various applications in the industrial sector, including motor protection, plant protection, short-circuit protection of starter combinations, transformer protection, as well as main and emergency stop switches. It can also be used in IT networks. Worldwide approval according to standards such as IEC and UL/CSA enables use in various markets. Additionally, variants for use in hazardous areas (ATEX or IEC Ex) are available, increasing application flexibility.
Functions and Equipment in Detail
The switch is equipped with a screw connection, enabling fast, maintenance-free, and vibration-resistant connection. The standard switching capacities are designed for typical requirements in industrial operation. The integrated overload relay function provides additional protection for the connected motor. The devices are part of the SIRIUS system building kit, which offers modular expandability. The 3RV2 series replaces the previous 3RV1 series and provides a current and efficient solution.
Technology Explained Simply
The CLASS 10 A-trip unit responds to overload situations within 10 seconds, ensuring precise and reliable protection. The N-trip unit with 432 A ensures rapid disconnection during short-circuit. The screw connection variant enables a mechanically stable connection that remains secure even under vibrations during operation. The low heat generation of the device is particularly advantageous in densely populated enclosures, where heat dissipation plays an important role.
Compatibility and Accessories
The device is compatible with a comprehensive range of accessories that are uniform across all sizes. Available accessories include auxiliary switches in various configurations, such as horizontal or side-mounted, as well as undervoltage release units and voltage release units. Examples include the auxiliary switch 3RV2901-1G (horizontal, 1 changeover contact) or the undervoltage release unit 3RV2902-1AV0 (440 V/60 Hz). Combining it with the SIRIUS 3RV29 power supply system significantly reduces main circuit wiring and simplifies installation.
Mounting and Installation
Mounting is done in standard enclosures. The screw connection allows for simple and secure connection of cables. The devices are designed for use in industrial environments and require no special mounting tools. Integration into existing systems is easy due to the uniform series and modular expandability.
Advantages in Operation
The power switch offers high reliability due to its robust construction and precise protection function. The low heat generation and weather-resistant design ensure long service life and low maintenance requirements. Worldwide approval and compatibility with a wide range of accessories increase flexibility during planning and installation. Use within the SIRIUS system building kit enables modular expansion and adaptation to specific requirements.
| General | |
| Construction size | S0 |
| A-trigger | CLASS 10 |
| A-trip unit adjustment range | 30-36 A |
| N-trigger | 432 A |
| Connection type | Screw connection |
| Switching capacity | Standard switching capacity |
| Application range | Motor protection |
| System | SIRIUS |
| Approvals | IEC, UL/CSA |
| Hazardous areas | ATEX, IEC Ex |
| Heat dissipation | low |
| Application | Consumer branch, IE3/IE4 motors |
| Accessory compatibility | auxiliary switch, undervoltage trip unit, voltage trip unit |
| Power supply system | SIRIUS 3RV29 |
Questions & answers
What is the delivery time of Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10?
The article Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10 is currently in stock
According to our experience the article is ready for dispatch within 2 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Siemens 3RV20214PA10 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10 always at the best possible price. We can give you a discount of 2% on Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Siemens 3RV20214PA10 Motor protection switch 36A 3RV2021-4PA10 we can offer you a price of 222,15 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
