Shuttle Barebone slim XH510G SO-DDR4
|
162,75 EUR |
|
|
( 193,67 EUR incl. VAT ) ≈ £137.52 | ≈ $181.95 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| End-Of-Life: | 26. Jul 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 1207150 |
| Mfg Part No: | XH510G |
| UPC/EAN: | 0887993005041 |
| Weight: | 3.029 kg |
Product information for Shuttle XH510G:
GLN HDMI DISPLAY-PORT
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| LED indicators | HDD, Power |
| Cable lock slot type | Kensington |
| Product type | PC barebone |
| On/off switch | |
| Cable lock slot | |
| VESA mounting | |
| Expansion slots | |
| PCI Express slots version | 4.0 |
| PCI Express x16 slots | 1 |
| Graphics | |
| Graphics card family | Intel |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 2666,2933,3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Non-ECC | |
| Network | |
| LAN controller | Intel® I219-LM |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Other features | |
| Country of origin | China |
| Packaging content | |
| Power cord included | |
| AC adapter included | |
| Quick start guide | |
| Drivers included | |
| Performance | |
| Motherboard chipset | Intel H510 |
| Processor socket | LGA 1200 (Socket H5) |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Audio output channels | 7.1 channels |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0a |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 180 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 9.23 A |
| Processor | |
| Built-in processor | |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | |
| Operating system installed | |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | M.2, Serial ATA III |
| Number of storage drives supported | 2 |
| NVMe | |
| Weight & dimensions | |
| Width | 250 mm |
| Depth | 200 mm |
| Height | 78.5 mm |
| Weight | 3.2 kg |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
Questions & answers
What is the delivery time of Shuttle Barebone slim XH510G SO-DDR4?
The article Shuttle Barebone slim XH510G SO-DDR4 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle XH510G to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Shuttle Barebone slim XH510G SO-DDR4 always at the best possible price. We can give you a discount of 2% on Shuttle Barebone slim XH510G SO-DDR4 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
