SHUTTLE Barebone SPCEL02 Intel Celeron J6412 1xSODIMM max 32GB DDR4 2.5G LAN
|
314,23 EUR |
|
|
( 373,93 EUR incl. VAT ) ≈ £265.52 | ≈ $351.31 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: 1 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1239134 |
| Mfg Part No: | SPCEL12 |
| UPC/EAN: | 0887993007243 |
| Weight: | 1.5 kg |
| Type: | BARE |
Product information for Shuttle SPCEL12:
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Chassis type | 0.46L sized PC |
| Product colour | Black, Blue |
| Cooling type | Passive |
| LED indicators | Power |
| Housing material | Aluminium |
| Panel mounting interface | 100 x 100 mm |
| Product type | Mini PC barebone |
| VESA mounting | |
| Graphics | |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| Maximum resolution | 3840 x 2160 pixels |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 1 |
| Maximum internal memory | 32 GB |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Single-channel |
| Memory voltage | 1.2 V |
| ECC | |
| Non-ECC | |
| Network | |
| LAN controller | Intel I226-V |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Packaging content | |
| Power cord included | |
| AC adapter included | |
| Performance | |
| Motherboard chipset | Intel SoC |
| Processor socket | BGA 1493 |
| Number of processors supported | 1 |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC888-VD |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Microphone in | |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 65 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.42 A |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | J6412 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 2.6 GHz |
| Processor frequency | 2 GHz |
| L2 cache | 1.5 MB |
| Thermal Design Power (TDP) | 10 W |
| Built-in processor | |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | |
| Operating system installed | |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | Serial ATA |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, VCCI |
| Weight & dimensions | |
| Width | 120 mm |
| Depth | 75 mm |
| Height | 51 mm |
| Weight | 720 g |
| Package weight | 1.2 kg |
