SHUTTLE Barebone SPCEL03 Intel Atom x6413E 1xSODIMM max 32GB DDR4 2x2.5G LAN
|
328,73 EUR |
|
|
( 391,19 EUR incl. VAT ) ≈ £277.78 | ≈ $367.52 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |
| In Stock: 1 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1239132 |
| Mfg Part No: | SPCEL03 |
| UPC/EAN: | 0887993007229 |
| Weight: | 1.2 kg |
| Type: | BARE |
Product information for Shuttle SPCEL03:
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Chassis type | 0.46L sized PC |
| Product colour | Black |
| Cooling type | Passive |
| LED indicators | Power |
| Housing material | Aluminium |
| Panel mounting interface | 100 x 100 mm |
| Product type | Mini PC barebone |
| VESA mounting | |
| Graphics | |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 1 |
| Maximum internal memory | 32 GB |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Single-channel |
| Memory voltage | 1.2 V |
| ECC | |
| Non-ECC | |
| Network | |
| LAN controller | Intel I226-V |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Packaging content | |
| AC adapter included | |
| Performance | |
| Motherboard chipset | Intel SoC |
| Processor socket | BGA 1493 |
| Number of processors supported | 1 |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| Ethernet LAN (RJ-45) ports | 2 |
| Serial ports quantity | 1 |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| AC adapter output voltage | 12 - 24 V |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
| Processor model | x6413E |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 3 GHz |
| Processor frequency | 1.5 GHz |
| L2 cache | 1.5 MB |
| Thermal Design Power (TDP) | 9 W |
| Built-in processor | |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | |
| Operating system installed | |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | Serial ATA |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, VCCI |
| Weight & dimensions | |
| Width | 120 mm |
| Depth | 75 mm |
| Height | 51 mm |
| Weight | 720 g |
| Package weight | 1.2 kg |
Questions & answers
What is the delivery time of SHUTTLE Barebone SPCEL03 Intel Atom x6413E 1xSODIMM max 32GB DDR4 2x2.5G LAN?
The article SHUTTLE Barebone SPCEL03 Intel Atom x6413E 1xSODIMM max 32GB DDR4 2x2.5G LAN is currently in stock
According to our experience the article is ready for dispatch within 7 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle SPCEL03 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you SHUTTLE Barebone SPCEL03 Intel Atom x6413E 1xSODIMM max 32GB DDR4 2x2.5G LAN always at the best possible price. We can give you a discount of 2% on SHUTTLE Barebone SPCEL03 Intel Atom x6413E 1xSODIMM max 32GB DDR4 2x2.5G LAN if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
