Shuttle DS50U Barebone Intel Celeron 7305 (fanless)
|
259,84 EUR |
|
|
( 309,21 EUR incl. VAT ) ≈ £219.56 | ≈ $290.50 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1214599 |
| Mfg Part No: | DS50U |
| UPC/EAN: | 0887993006574 |
| Weight: | 2.875 kg |
| Type: | BARE |
Product information for Shuttle DS50U:
LAN HDMI DISPLAY-PORT COM-PORT
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Chassis type | 1.3L sized PC |
| Product colour | Black |
| Cooling type | Passive |
| LED indicators | HDD, Power |
| Housing material | Steel |
| Cable lock slot type | Kensington |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Product type | Mini PC barebone |
| On/off switch | |
| Cable lock slot | |
| VESA mounting | |
| Graphics | |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 5200 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 V |
| Network | |
| LAN controller | Intel® I219, Intel I226-LM |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging content | |
| Power cord included | |
| AC adapter included | |
| Quick start guide | |
| Performance | |
| Number of processors supported | 1 |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | RealTek ALC888S |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Serial ports quantity | 1 |
| Microphone in | |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 90 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 1.6 A |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | 7305 |
| Processor cores | 5 |
| Processor threads | 5 |
| Performance cores | 1 |
| Efficient cores | 4 |
| Built-in processor | |
| ECC supported by processor | |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | |
| Operating system installed | |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | PCI Express, Serial ATA III |
| Number of storage drives supported | 3 |
| NVMe | |
| Sustainability | |
| Sustainability certificates | ENERGY STAR, ErP |
| Sustainability compliance | |
| Technical details | |
| Compliance certificates | BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI, cTUVus |
| Weight & dimensions | |
| Width | 200 mm |
| Depth | 165 mm |
| Height | 39.5 mm |
| Weight | 1.6 kg |
| Package weight | 2.3 kg |
Questions & answers
What is the delivery time of Shuttle DS50U Barebone Intel Celeron 7305 (fanless)?
The article Shuttle DS50U Barebone Intel Celeron 7305 (fanless) is currently in stock
According to our experience the article is ready for dispatch within 7 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle DS50U to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Shuttle DS50U Barebone Intel Celeron 7305 (fanless) always at the best possible price. We can give you a discount of 2% on Shuttle DS50U Barebone Intel Celeron 7305 (fanless) if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
