SHUTTLE Barebone XPC slim DN11H7 Intel Core Ultra 7 155H 2xSODIMM 3xM.2 1xM.2 for WLAN module 2xHDMI 2xDP
|
790,76 EUR |
|
|
( 941,01 EUR incl. VAT ) ≈ £668.20 | ≈ $884.08 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1606818 |
| Mfg Part No: | DN11H7 |
| UPC/EAN: | 0887993007304 |
| Weight: | 2.372 kg |
| Type: | BARE |
Product information for Shuttle DN11H7:
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Chassis type | 1.35L sized PC |
| Product colour | Black |
| Cooling type | Active |
| Housing material | Metal |
| Cable lock slot type | Kensington |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Product type | Mini PC barebone |
| Cable lock slot | |
| VESA mounting | |
| Graphics | |
| Graphics card family | Intel |
| On-board graphics card model | Intel Arc Graphics |
| Maximum resolution | 3840 x 2160 pixels |
| Number of displays supported | 4 |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 96 GB |
| Supported memory clock speeds | 5600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 V |
| ECC | |
| Non-ECC | |
| Network | |
| LAN controller | Intel I226-LM |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging content | |
| Power cord included | |
| AC adapter included | |
| Quick start guide | |
| Performance | |
| Motherboard chipset | Intel SoC |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC888S |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| Microphone in | |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 120 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 6.32 A |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor generation | Intel® Core™ Ultra (Series 1) |
| Processor model | 155H |
| Processor cores | 16 |
| Processor threads | 22 |
| Processor boost frequency | 4.8 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 4.8 GHz |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Performance-core base frequency | 1.4 GHz |
| Efficient-core base frequency | 0.9 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 24 MB |
| Built-in processor | |
| Software | |
| Windows operating systems supported | Windows 11 x64 |
| Linux operating systems supported | |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express |
| NVMe | |
| Sustainability | |
| Sustainability certificates | ENERGY STAR, ErP |
| Technical details | |
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), RoHS, cTUVus |
| Weight & dimensions | |
| Width | 190 mm |
| Depth | 165 mm |
| Height | 43 mm |
| Weight | 1.23 kg |
| Package weight | 2.46 kg |
Questions & answers
What is the delivery time of SHUTTLE Barebone XPC slim DN11H7 Intel Core Ultra 7 155H 2xSODIMM 3xM.2 1xM.2 for WLAN module 2xHDMI 2xDP?
The article SHUTTLE Barebone XPC slim DN11H7 Intel Core Ultra 7 155H 2xSODIMM 3xM.2 1xM.2 for WLAN module 2xHDMI 2xDP is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle DN11H7 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you SHUTTLE Barebone XPC slim DN11H7 Intel Core Ultra 7 155H 2xSODIMM 3xM.2 1xM.2 for WLAN module 2xHDMI 2xDP always at the best possible price. We can give you a discount of 2% on SHUTTLE Barebone XPC slim DN11H7 Intel Core Ultra 7 155H 2xSODIMM 3xM.2 1xM.2 for WLAN module 2xHDMI 2xDP if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
