SHUTTLE Barebone XPC slim DH770 LGA1700 2xSODIMM 2xM.2 2xHDMI 2xDP
|
308,19 EUR 308,19 EUR |
|
|
( 366,74 EUR incl. VAT ) ≈ £260.42 | ≈ $344.55 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >25 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1219983 |
| Mfg Part No: | DH770 |
| UPC/EAN: | 0887993006918 |
| Weight: | 2.679 kg |
| Type: | BARE |
Product information for Shuttle DH770:
| Audio | |
| Built-in speaker(s) | |
| Design | |
| Chassis type | 1.35L sized PC |
| Product colour | Black |
| Cooling type | Active |
| LED indicators | HDD, Power |
| Housing material | Metal |
| Cable lock slot type | Kensington |
| Panel mounting interface | 100 x 75 mm |
| Product type | Mini PC barebone |
| On/off switch | |
| Cable lock slot | |
| VESA mounting | |
| Graphics | |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 5600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 V |
| Internal memory installed | |
| ECC | |
| Non-ECC | |
| Network | |
| LAN controller | Intel I226-LM |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Other features | |
| Country of origin | China |
| Packaging content | |
| Power cord included | |
| AC adapter included | |
| Drivers included | |
| Performance | |
| Motherboard chipset | Intel H770 |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC888S |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Serial ports quantity | 2 |
| Microphone in | |
| Combo headphone/mic port | |
| DC-in jack | |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 120 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 6.32 A |
| Processor | |
| Built-in processor | |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | PCI Express, Serial ATA III |
| Storage drives installed | |
| NVMe | |
| Sustainability | |
| Sustainability certificates | ENERGY STAR, ErP |
| Technical details | |
| Compliance certificates | BSMI, CB, CE, ETL, Federal Communications Commission (FCC), RCM, RoHS, VCCI |
| Weight & dimensions | |
| Width | 190 mm |
| Depth | 165 mm |
| Height | 43 mm |
| Weight | 1.3 kg |
| Package weight | 2.1 kg |
Questions & answers
What is the delivery time of SHUTTLE Barebone XPC slim DH770 LGA1700 2xSODIMM 2xM.2 2xHDMI 2xDP?
The article SHUTTLE Barebone XPC slim DH770 LGA1700 2xSODIMM 2xM.2 2xHDMI 2xDP is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle DH770 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you SHUTTLE Barebone XPC slim DH770 LGA1700 2xSODIMM 2xM.2 2xHDMI 2xDP always at the best possible price. We can give you a discount of 2% on SHUTTLE Barebone XPC slim DH770 LGA1700 2xSODIMM 2xM.2 2xHDMI 2xDP if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
