SHUTTLE Box-PC System BPCAL02 Intel Core i5-1235U 8GB DDR5 256GB SSD W10IoT Enterprise
|
1.117,01 EUR 1.117,01 EUR |
|
|
( 1.329,24 EUR incl. VAT ) ≈ £943.87 | ≈ $1,248.82 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| End-Of-Life: | 01. Jul 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 121536 |
| Mfg Part No: | BPCAL02-I5WA |
| UPC/EAN: | 4046047104222 |
| Weight: | 0 kg |
Product information for Shuttle BPCAL02-I5WA:
| Audio | |
| Audio chip | Realtek ALC888S |
| Certificates | |
| Compliance certificates | BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI, cTUVus |
| Design | |
| Chassis type | USFF |
| Volume | 2.7 L |
| Product colour | Black, Blue |
| Housing material | Aluminium, Steel |
| VESA mounting | |
| Display | |
| Display included | |
| Graphics | |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| Discrete graphics card | |
| On-board graphics card | |
| Logistics data | |
| Harmonized System (HS) code | 84714900 |
| Memory | |
| Internal memory | 8 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 4800 MHz |
| Network | |
| Ethernet LAN data rates | 2500 Mbit/s |
| LAN controller | Intel I226-V |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Performance | |
| Market positioning | Industry |
| BIOS type | UEFI AMI |
| Product type | Mini PC |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | |
| Trusted Platform Module (TPM) | |
| Ports & interfaces | |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 3 |
| Microphone in | |
| DC-in jack | |
| Power | |
| Power supply | 90 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor model | i5-1235U |
| Processor cores | 10 |
| Processor threads | 12 |
| Processor boost frequency | 4.4 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4.4 GHz |
| Efficient-core Max Turbo Frequency | 3.3 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor base power | 15 W |
| Maximum turbo power | 55 W |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 IoT Enterprise |
| Drivers included | |
| Storage | |
| Total storage capacity | 250 GB |
| Storage media | SSD |
| Total SSDs capacity | 250 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 250 GB |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Optical drive type | |
| NVMe | |
| Sustainability | |
| Sustainability certificates | ErP |
| Weight & dimensions | |
| Width | 245 mm |
| Depth | 169 mm |
| Height | 57 mm |
| Weight | 2.85 kg |
Questions & answers
What is the delivery time of SHUTTLE Box-PC System BPCAL02 Intel Core i5-1235U 8GB DDR5 256GB SSD W10IoT Enterprise?
The article SHUTTLE Box-PC System BPCAL02 Intel Core i5-1235U 8GB DDR5 256GB SSD W10IoT Enterprise is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Shuttle BPCAL02-I5WA to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you SHUTTLE Box-PC System BPCAL02 Intel Core i5-1235U 8GB DDR5 256GB SSD W10IoT Enterprise always at the best possible price. We can give you a discount of 2% on SHUTTLE Box-PC System BPCAL02 Intel Core i5-1235U 8GB DDR5 256GB SSD W10IoT Enterprise if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
