Schneider Electric TM5SDO16T Schneider Digital Output Module 16A 24VDC 0

This product is part of the Modicon TM5 range, a range of modules for modular IP20 I/O systems. The digital output module offers 16 transistor outputs with source logic (negative). It is an output module with a discrete input voltage of 24V DC, an input current consumption of 56mA at 5V DC bus, 40mA at 24V DC. This product is part of a flexible and scalable I/O configuration for automation solutions. There is isolation between channel and bus at 500Vrms AC and no isolation between channels. It is equipped with a single cable for electrical connection. It is an IP20 product. It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machines as well as material handling and assembly systems. This product is certified by CE, CULus, GOST-R, CSA and C-Tick. It complies with IEC 61131-2, CSA C22.2 No. 142, CSA C22.2 No. 213 and UL 508 standards. This product is compatible with PacDrive LMC Pro, PacDrive LMC Pro 2, PacDrive LMC Eco, logic controller and motion controller. The range is compatible with PacDrive LMC, Modicon LMC058 Motion Controller and Modicon M258 Logic Controller. This modular IP20 IO system offers a flexible and scalable configuration of extensions/distributed I/O islands. This is possible by connecting to Modicon controllers (TM5 bus) or via CANopen bus/Sercos bus for Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Type: TM5SDO16T
