Schneider Electric TM5SDI16D
Schneider digital input module 16E 24VDC with derivation 1 cable

This product is part of the Modicon TM5 range, an offering of modules for modular IP20 I/O systems. The digital input module has 16 inputs with sink logic (positive). It is an input module with a nominal supply voltage of 24V DC, a current consumption of 36mA at 5V DC bus, 61mA at 24V DC all inputs on and a maximum power dissipation of 1.65W. This product is part of a flexible and scalable I/O configuration for automation solutions. There is isolation between channel and bus at 500Vrms AC and no isolation between channels. It is equipped with a single wire for electrical connection. It is an IP20 product. It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machines as well as material flow and assembly systems. This product is certified by CE, CULus, GOST-R, CSA and C-Tick. It complies with IEC 61131-2, CSA C22.2 No. 142, CSA C22.2 No. 213 and UL 508 standards. This product is compatible with PacDrive LMC Pro, PacDrive LMC Pro 2, PacDrive LMC Eco, logic controller and motion controller. The range is compatible with PacDrive LMC, Modicon LMC058 Motion Controller and Modicon M258 Logic Controller. This modular IP20 IO system offers a flexible and scalable configuration of extensions/distributed I/O islands. This is possible by connecting to Modicon controllers (TM5 bus) or via CANopen bus/Sercos bus for Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Type: TM5SDI16D
