Schneider Electric 170AAO92100 MOMENTUM 4AO+/-10V 4-20mA 12BIT+
|
-13% 1.030,86 EUR 1.179,90 EUR |
|
|
( 1.226,72 EUR incl. VAT ) ≈ £859.74 | ≈ $1,152.50 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 592496 |
| Mfg Part No: | 170AAO92100 |
| UPC/EAN: | 3595861147720 |
| Weight: | 0.375 kg |
| Type: | 170AAO92100 |
Product information for Schneider Electric 170AAO92100:
| Complementary | |
| Data format | Full 16 bits signed |
| Analogue output range | +/- 10 V 12 bits + sign >= 1 kOhm; 4...20 mA 12 bits + sign |
| Maximum load capacitance | 1 µF |
| Absolute accuracy error | +/- 0.2 % of full scale +/- 10 V 25 °C; +/- 0.25 % full scale +/- 10 V 60 °C; +/- 0.4 % of full scale 4...20 mA 25 °C; +/- 0.5 % of full scale 4...20 mA 60 °C |
| Update time | 2 ms |
| Full scale | 10 V +/- 10 V; 2 mA 4...20 mA |
| Fail state | Hold; Reset to full scale; Reset to zero |
| Protection type | Internal 2 A slow-blow |
| Output short-circuit protection | With in voltage circuit |
| External power requirement | +/- 30 V DC; 24 V DC |
| Permissible common mode voltage | 250 V 47...63 Hz AC between channels to ground; 250 V 47...63 Hz DC |
| Reverse polarity protection | Internal |
| Module format | Standard |
| Temperature drift | 10 %oFS/°C; 30 %oFS/°C |
| Typical current consumption | 150 mA at 24 V DC; 530 mA at 24 V DC |
| Power dissipation in W | 8.5 W |
| Isolation between channels and ground | 500 V AC |
| Local signalling | 4 LEDs for channel status |
| Height | 125 mm |
| Width | 141.5 mm |
| Depth | 47.5 mm |
| Net weight | 0.215 kg |
| Contractual warranty | |
| Warranty (in months) | 18 |
| Environment | |
| Protective treatment | TC |
| Marking | CE |
| Product certifications | UL; CSA |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Logistical informations | |
| Country of origin | ID |
| Main | |
| Range of product | Modicon Momentum automation platform |
| Product or component type | Analogue output base |
| Analogue output number | 4 |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.5 cm |
| Package 1 Width | 18.0 cm |
| Package 1 Length | 26.0 cm |
| Package 1 Weight | 375.0 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 3.75 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 80 |
| Package 3 Height | 75.0 cm |
| Package 3 Width | 40.0 cm |
| Package 3 Length | 80.0 cm |
| Package 3 Weight | 45 kg |
Questions & answers
What is the delivery time of Schneider Electric 170AAO92100 MOMENTUM 4AO+/-10V 4-20mA 12BIT+?
The article Schneider Electric 170AAO92100 MOMENTUM 4AO+/-10V 4-20mA 12BIT+ is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schneider Electric 170AAO92100 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schneider Electric 170AAO92100 MOMENTUM 4AO+/-10V 4-20mA 12BIT+ always at the best possible price. We can give you a discount of 2% on Schneider Electric 170AAO92100 MOMENTUM 4AO+/-10V 4-20mA 12BIT+ if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
