Rittal 9360525 RX CB-device adapter 400 A 3-pole Easy Fix W:140 mm

Your rating:
Average rating
product review for Rittal 9360525 RX CB-device adapter 400 A 3-pole Easy Fix W:140 mm
( 5 / 5 ) 1 ratings
Rittal 9360525
This image may differ from the desired article.
Rittal 9360525Rittal 9360525Rittal 9360525Rittal 9360525Rittal 9360525Rittal 9360525
-6% 166,75 EUR 178,27 EUR
( 198,43 EUR incl. VAT )
≈ £139.40  |  ≈ $184.26
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 5 workdaysinfo_outline
In Stock: 1 pieces
1x Rittal 9360525 RX CB-device adapter 400 A 3-pole Easy Fix W:140 mm
Datasheet:file_download Download
Lieske Part No.:612019
Mfg Part No: 9360525
UPC/EAN: 4028177997127
Weight:4.298 kg
Type:RX 9360525

Product information for Rittal 9360525:

The Rittal RX 9360525 is a CB device adapter for 60 mm busbar systems, specifically designed for use in industrial enclosures. The Easy-Fix concept enables tool-free snap-in mounting, allowing the adapter and switch to be mounted independently. This simplifies the pre-assembly of market-standard switch types outside the enclosure and reduces installation time in the final device.

Applications

The adapter is designed for use in industrial electrical installations, particularly in enclosures with RiLineX or RiLine60 busbar systems. It is suitable for applications requiring flexible and rapid mounting of power switches, for example in manufacturing automation, power distribution, or process control. The compatibility with busbars of dimensions 15 x 5/10 mm, 20 x 5/10 mm, and 30 x 5/10 mm ensures broad compatibility with various busbar systems.

Functions and Features in Detail

The adapter features tool-free snap-in mounting, available up to 250 A. The busbar thickness can be adjusted semi-automatically between 5 mm and 10 mm, enabling adaptation to different busbar profiles. The cable exit can be easily reconfigured from top to bottom or vice versa, depending on requirements. Electrical connection is made via M10 screw, supporting cross-sections of 29 mm² and 6 mm². The delivery includes 3 terminal covers, which provide secure coverage of the terminals.

Technical Explanation

The adapter is made of polyamide (PA 6), which, according to UL 94, exhibits specific flammability characteristics relevant for safety in electrical installations. The protection rating IP 2XB according to IEC 60 529 protects against finger contact and solid foreign objects, but not against water or dust. The pollution degree 3 indicates suitability for environments with heavy contamination, such as industrial facilities with dust or chemical influences. The rated voltage is 690 V AC (600 V AC UL), and the rated insulation voltage is 800 V for 5 mm busbar thickness and 1,000 V for 10 mm. The rated impulse voltage is 8 kV, indicating the device’s ability to withstand electrical overvoltages. The power loss is limited to a maximum of 19.5 W, minimizing thermal load during operation.

Compatibility and Accessories

The adapter is designed for busbar systems RiLineX and RiLine60. Compatible accessories include the enclosure protection profile RX 9365025 (length 1200 mm) and mounting clips RX 9365027 (for 24 pieces), which ensure secure mounting and protection of the busbars. These components can be used additionally to enhance the safety and stability of the installation.

Mounting and Installation

Mounting is performed tool-free by snapping the adapter onto the busbar. Adjustment of the busbar thickness is done via integrated adjustment discs, enabling user-friendly adaptation. Pre-assembly of switches outside the enclosure is possible, accelerating installation in the final device. Adjustment of the cable exit is achieved through simple reconfiguration, allowing installation to be adapted to individual requirements.

Operational Advantages

Using the Rittal RX 9360525 reduces installation time and increases flexibility when installing power switches. The tool-free mounting and the possibility of pre-assembly outside the enclosure reduce field work effort. High compatibility with various busbar systems and the robust polyamide construction ensure reliable and safe operation in industrial environments. The operating temperature range of -25 °C to 55 °C and the storage temperature range of -25 °C to 75 °C allow use in a wide range of environments, even under extreme temperatures. The humidity range of 10 to 90 % (non-condensing) is suitable for typical industrial applications.

General
ModelEasy Fix
MaterialPolyamide (PA 6), flammability according to UL 94
ColourRAL 9005, RAL 35745
Scope of deliveryIncluding 3 terminal covers
Degree of protection IP according to IEC 60 529IP 2XB
Rated impulse voltage Uimp8 kV
Rated voltage690 V AC, 600 V AC (UL)
Rated insulation voltage Uiat rail thickness 5 mm: 800 V, at rail thickness 10 mm: 1,000 V
Pollution degree3
Number of poles3-pole
Cable exitAbove/under
Electrical connection typeM10 screw
Cross section29 mm², 6 mm²
Suitable for manufacturer (type)Easily find the appropriate device adapter using our selection guide in the Downloads section.
Suitable for busbar systemRiLineX, RiLine60
Maximum power dissipation19,5 W
Frequency of fundamental wave50...60 Hz
Humidity (non-condensing)10...90 %
Suitable for busbars15 x 5/10 mm, 20 x 5/10 mm, 30 x 5/10 mm
Operating temperature range-25 °C...55 °C
Storage temperature range-25 °C...75 °C
Width145 mm
Height325,8 mm
Fire load22,239 MJ/m²
Copper content (kg/piece)1,652
PCF/VE (Cradle-to-Gate)19,01


Product data sheet
