Rittal 5302033 VX IT sliding rails fixed installation 620/645, 200 kg, 2 U

Your rating:
Average rating
product review for Rittal 5302033 VX IT sliding rails fixed installation 620/645, 200 kg, 2 U
( 4.5 / 5 ) 2 ratings
Rittal 5302033
This image may differ from the desired article.
Rittal 5302033Rittal 5302033Rittal 5302033Rittal 5302033
69,58 EUR
( 82,80 EUR incl. VAT )
≈ £58.24  |  ≈ $76.47
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >100 pieces
1x Rittal 5302033 VX IT sliding rails fixed installation 620/645, 200 kg, 2 U
Datasheet:file_download Download
Lieske Part No.:1910604
Mfg Part No: 5302033
UPC/EAN: 4028177952621
Weight:2.18 kg
Type:VX 5302033

Product information for Rittal 5302033:

The Rittal sliding rail VX 5302033 is a system accessory for use in the VX IT enclosure, specifically designed for fixed installation and support of heavy components. The product serves as a mounting connection between the front and rear 48,3 cm ( 19 inch ) mounting planes and enables secure installation of devices requiring high static load capacity. The sliding rail is made of sheet steel and features a galvanized surface, providing high corrosion resistance. It is designed for use in industrial environments where a robust and reliable mounting component is required.

Applications

The sliding rail is primarily intended for use in VX IT enclosures, where it is mounted between the front and rear 48,3 cm ( 19 inch ) mounting planes. It serves to stabilize and support heavy installations, such as servers, network devices, or other IT components that generate high static loads. Installation is carried out via the lateral system perforation of the 48,3 cm ( 19 inch ) mounting profiles, enabling simple and quick installation without additional tools. The effective bearing surface is 35 mm per side, ensuring secure load distribution.

Functions and Features in Detail

The sliding rail has a height of 2 HE (unit height) and is designed for fixed installation. It is inserted into the system perforation of the 48,3 cm ( 19 inch ) mounting profiles after the desired spacing between mounting levels has been set. Installation requires no additional drilling or screw connections, which speeds up the process and avoids damaging the enclosure structure. The product is designed for a static load capacity of 2000 N, equivalent to approximately 200 kg. The galvanized surface provides high corrosion protection, especially in humid or industrial environments.

Technology Explained Simply

The sliding rail uses the lateral system perforation of the 48,3 cm ( 19 inch ) mounting profiles to securely anchor itself in the front mounting plane. The lateral holes allow for easy insertion and secure positioning without additional fastening elements. The static load capacity of 2000 N is sufficient for use in enclosures with heavy devices, with the load evenly distributed over the bearing surface of 35 mm per side. The galvanized sheet steel surface protects against corrosion and extends the product’s service life.

Compatibility and Accessories

The sliding rail is compatible with 48,3 cm ( 19 inch ) profile rails in standard and dynamic variants. Installation options include spacing between mounting levels of 620/645 mm for the standard profile rail and 600/625 mm for the dynamic profile rail. Compatible accessories available in the range include 48,3 cm ( 19 inch ) fasteners 1 HE with electrical connection, which can be used for additional mounting or cabling. The sliding rail is supplied in a pack of 2 pieces and includes the required mounting hardware.

Installation and Mounting

Installation is performed by simply inserting the sliding rail into the lateral system perforation of the 48,3 cm ( 19 inch ) mounting profiles. The mounting profiles must first be adjusted to the desired spacing between levels. The sliding rail is then inserted into the front mounting plane and secured using the included mounting hardware. The installation requires no additional tools or drilling, reducing installation time and protecting the enclosure structure.

Operational Advantages

The sliding rail provides a secure and stable mounting solution for heavy components in the VX IT enclosure. The static load capacity of 2000 N ensures high safety, even under heavy loads. The galvanized surface ensures long service life, even in humid or corrosive environments. The simple installation via system perforation reduces installation time and minimizes the risk of damage to the enclosure. Compatibility with various 48,3 cm ( 19 inch ) profile rail variants increases flexibility in planning and installing enclosures.

General
ApplicationsFor mounting between front and rear 19" mounting planes, For supporting heavy installations
Materialsteel sheet
Surface protectionZinc-plated
Scope of deliveryIncluding mounting hardware
Load capacity2000 N, static
NoteEffective contact area per side 35 mm
Mounting optionsFor 19" profile rail standard: spacing 620/645 mm, for 19" profile rail dynamic: spacing 600/625 mm
PCF/VE (Cradle-to-Gate)8.3 kg CO2 eq (Cat B)
Note on PCF classCategory B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared


Product data sheet
Datasheet for Rittal 5302033, EAN: 4028177952621
