Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm

Your rating:
Average rating
product review for Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm
( 4.5 / 5 ) 2 ratings
Rittal 5301244
This image may differ from the desired article.
Rittal 5301244Rittal 5301244Rittal 5301244
312,57 EUR
( 371,96 EUR incl. VAT )
≈ £261.62  |  ≈ $343.51
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >10 pieces
1x Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm
Datasheet:file_download Download
Lieske Part No.:1775854
Mfg Part No: 5301244
UPC/EAN: 4028177955851
Weight:30.8 kg
Type:VX 5301244

Product information for Rittal 5301244:

The Rittal side panel VX 5301244 is a vertically divided replacement part for enclosures of type VX IT, specifically designed for an enclosure height of 2,200 mm and a depth of 1,000 mm. The product is made of steel sheet and features a powder coating in the color RAL 7035, providing a robust surface with uniform coloration and corrosion protection. The protection rating IP 20 according to IEC 60529 ensures protection against solid foreign objects larger than 12.5 mm and against vertically falling water droplets, making the side panel suitable for use in indoor environments where no special conditions such as humidity or dust prevail.

Applications

The side panel serves as a replacement or supplementary part for industrial enclosures of the VX IT system. It is used in installations requiring modular, tool-free assembly and disassembly, for example in automation technology, manufacturing industry, or when installing control systems. The vertical division allows flexible adaptation to different enclosure configurations and facilitates access to the internal components.

Functions and Equipment in Detail

The side panel is equipped with 4 quick-release fasteners, enabling simple and fast closing. Installation is carried out via an integrated mounting rail, which supports the attachment of the side parts to the enclosure structure. The hinges ensure a stable connection of the side parts, while the quick-release fasteners provide secure locking.

Technology Explained Simply

The construction of the side panel allows for tool-free disassembly of individual side parts, which is advantageous during maintenance work or when replacing components within the enclosure. Opening the side panels is possible only via internal locking elements, meaning access through the front and rear doors of the enclosure must always be ensured. This increases access security, as unauthorized access to the internal components is prevented. The powder coating ensures high mechanical durability and uniform surface quality, which remains intact even under mechanical stress during operation.

Compatibility and Accessories

The side panel is specifically designed for enclosures of type VX IT with a height of 2,200 mm and a depth of 1,000 mm. As suitable accessories, the internal locking DK 7824510 is offered, which enables additional securing of the side panels and further increases access security. This locking is intended for lockable side panels and can be optionally added to enhance protection of installed components.

Installation and Mounting

Mounting is tool-free via the provided hinges and quick-release fasteners. The mounting rail facilitates attachment to the enclosure structure. An important installation note is that access through the front and rear doors of the enclosure must always be possible, as opening the side panels is done via internal locking elements. Therefore, installation is only possible if the doors are freely accessible.

Operational Advantages

The tool-free disassembly and mounting of the side parts reduces installation time and simplifies maintenance work. The use of quick-release fasteners and hinges ensures a secure and stable locking mechanism that remains reliable even with frequent opening and closing. The robust steel sheet construction with powder coating guarantees long service life and high mechanical load capacity. Compatibility with the VX IT system enables easy integration into existing enclosure configurations.

General
Materialsteel sheet
Surface protectionPowder-coated
ColourRAL 7035
Scope of delivery2 side panels, mounting rail, 6 hinges, 4 quick-release fasteners, including fastening material
Mounting noteAccess through front and rear doors must be ensured
Suitable forCabinet type: VX IT, height: = 2.200 mm, depth: = 1.000 mm
Degree of protection IP according to IEC 60 529IP 20
Base materialsteel sheet
PCF/VE (Cradle-to-Gate)117.3 kg CO2 eq (Cat B)
Note on PCF classCategory B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared


Please note...
This article has over-size and needs to be seperately taken care of. This is why we want to inform you, that the calculation of the delivery charges in the shopping cart will disregard this aspect. Though, there will be corresponding surcharges after you send us your order.
Product data sheet
Datasheet for Rittal 5301244, EAN: 4028177955851

Questions & answers

What is the delivery time of Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm?

The article Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm is currently in stock

According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 5301244 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm always at the best possible price. We can give you a discount of 2% on Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.




Fitting accessory for Rittal 5301244 VX IT side panel, vertically divided, 2200x1000 mm

Rittal 7824510 DK internal locking 1=4 for lockable side panels Rittal LogoRittal 7824510 DK internal locking 1=4 for lockable side panels The Rittal internal locking system, type DK 7824510, is a system accessory for enclosures, specifically designed for securing lockable side panels to the internal frame profile. This locking system ...

Lieske Part No.: 925072
Mfg Part No: 7824510
Type: DK 7824510
21,06 EUR 21,99 EUR
Rittal 7824510 plus VAT
