RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U
|
912,00 EUR |
|||||||||||
|
( 1.085,28 EUR incl. VAT ) ≈ £761.52 | ≈ $1,022.35 plus delivery charges: 235,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 969506 | ||||||||||
| Mfg Part No: | WFC-012 U | ||||||||||
| UPC/EAN: | 4250458250601 | ||||||||||
| Weight: | 20.2 kg | ||||||||||
| Type: | WFC-012U | ||||||||||
|
Graduated prices net
|
|||||||||||
Further Cases from RCS Audio-SystemsFurther products in category Cases
All products of RCS Audio-Systems
Product information for RCS Audio-Systems WFC-012 U:
The WFC-012 U from RCS Audio-Systems is a 48,3 cm ( 19 inch ) angled flight case with 12 height units (HE), specifically designed for professional use in event technology. It is intended for the secure transport and mounting of 48,3 cm ( 19 inch ) rack-mounted devices during tours, stage installations, and shipping via freight or air freight. The case conforms to the international 48,3 cm ( 19 inch ) standard and is designed for use in demanding environments.
Applications
This flight case is intended for use in professional event technology, live events, stage setups, and logistics for audio and video equipment. Its construction enables the safe transport of sensitive devices over long distances and under varying conditions, including air freight and freight shipping. The robust design protects the mounted devices from mechanical stress, impacts, and environmental influences.
Features and Equipment in Detail
The body of the WFC-012 U is made of 7 mm thick, multi-layered birch plywood in Double Door" configuration, ensuring high stability and durability. The mounting depth is 500 mm, providing sufficient space for deep 19 rack-mounted devices. An adjustable rack rail in the upper section allows for ergonomic angled positioning of mixers or control panels, improving operability during use. The entire outer edge of the case is protected by continuous aluminium profiles (25/25 mm), which provide additional stability and protection against edge damage.
Technology Explained Simply
The 12 height units (HE) correspond to a mounting height of 545 mm, with one HE equaling 44.45 mm. The overall height of the case is 670 mm, the overall width is 550 mm, and the overall depth is 685 mm. The mounting depth of 500 mm is particularly suitable for devices with greater depth, such as mixing consoles or amplifiers. The aluminium profiles and the 8 zinc-plated corner protectors on the outer corners increase mechanical strength and protect against corner and edge damage. The 4 recessed folding handles and spring-loaded butterfly latches ensure secure and convenient transport. The 4 non-slip rubber feet on the underside provide stable positioning of the case on various surfaces.
Compatibility and Accessories
The WFC-012 U is designed for mounting 48,3 cm ( 19 inch ) rack-mounted devices and conforms to the international 48,3 cm ( 19 inch ) standard. It is equipped with an adjustable rack rail suitable for angled positioning of mixers or control panels. As an accessory, a roll base (RUS-101) is available, made of sturdy plywood and equipped with 4 swivel castors (100 mm). This enables mobile use of the case, especially for longer transport distances.
Mounting and Installation
Mounting is done via the integrated 48,3 cm ( 19 inch ) rack rail, designed for securing devices according to the 48,3 cm ( 19 inch ) standard. The adjustable rack rail in the upper section can be used for angled positioning of mixers or control panels. Installation is carried out using the mounting materials included in the delivery scope, which vary depending on the model. Access to the interior is provided via three removable lids on the front, rear, and top sides, enabling flexible and quick mounting and maintenance of the devices.
Advantages in Operation
The WFC-012 U offers high stability and protection for sensitive equipment. The robust construction from birch plywood and additional protective profiles ensure a long service life. The ergonomic angled positioning of the rack rail improves operability during use. The integrated handles and latches facilitate transport, while the rubber feet ensure secure positioning. The mounting depth of 500 mm allows for installation of deep devices, increasing flexibility in use. The case is designed for professional environments and meets requirements for quality, stability, and functionality.
Delivery Scope
The delivery scope includes the flight case WFC-012 U, three removable lids (on front, rear, and top sides), and the required mounting materials, which vary depending on the model.
Applications
This flight case is intended for use in professional event technology, live events, stage setups, and logistics for audio and video equipment. Its construction enables the safe transport of sensitive devices over long distances and under varying conditions, including air freight and freight shipping. The robust design protects the mounted devices from mechanical stress, impacts, and environmental influences.
Features and Equipment in Detail
The body of the WFC-012 U is made of 7 mm thick, multi-layered birch plywood in Double Door" configuration, ensuring high stability and durability. The mounting depth is 500 mm, providing sufficient space for deep 19 rack-mounted devices. An adjustable rack rail in the upper section allows for ergonomic angled positioning of mixers or control panels, improving operability during use. The entire outer edge of the case is protected by continuous aluminium profiles (25/25 mm), which provide additional stability and protection against edge damage.
Technology Explained Simply
The 12 height units (HE) correspond to a mounting height of 545 mm, with one HE equaling 44.45 mm. The overall height of the case is 670 mm, the overall width is 550 mm, and the overall depth is 685 mm. The mounting depth of 500 mm is particularly suitable for devices with greater depth, such as mixing consoles or amplifiers. The aluminium profiles and the 8 zinc-plated corner protectors on the outer corners increase mechanical strength and protect against corner and edge damage. The 4 recessed folding handles and spring-loaded butterfly latches ensure secure and convenient transport. The 4 non-slip rubber feet on the underside provide stable positioning of the case on various surfaces.
Compatibility and Accessories
The WFC-012 U is designed for mounting 48,3 cm ( 19 inch ) rack-mounted devices and conforms to the international 48,3 cm ( 19 inch ) standard. It is equipped with an adjustable rack rail suitable for angled positioning of mixers or control panels. As an accessory, a roll base (RUS-101) is available, made of sturdy plywood and equipped with 4 swivel castors (100 mm). This enables mobile use of the case, especially for longer transport distances.
Mounting and Installation
Mounting is done via the integrated 48,3 cm ( 19 inch ) rack rail, designed for securing devices according to the 48,3 cm ( 19 inch ) standard. The adjustable rack rail in the upper section can be used for angled positioning of mixers or control panels. Installation is carried out using the mounting materials included in the delivery scope, which vary depending on the model. Access to the interior is provided via three removable lids on the front, rear, and top sides, enabling flexible and quick mounting and maintenance of the devices.
Advantages in Operation
The WFC-012 U offers high stability and protection for sensitive equipment. The robust construction from birch plywood and additional protective profiles ensure a long service life. The ergonomic angled positioning of the rack rail improves operability during use. The integrated handles and latches facilitate transport, while the rubber feet ensure secure positioning. The mounting depth of 500 mm allows for installation of deep devices, increasing flexibility in use. The case is designed for professional environments and meets requirements for quality, stability, and functionality.
Delivery Scope
The delivery scope includes the flight case WFC-012 U, three removable lids (on front, rear, and top sides), and the required mounting materials, which vary depending on the model.
| Technical data | |
| Mounting height (internal) | 545 mm |
| Overall width (external) | 550 mm |
| Overall depth (external) | 685 mm |
| Height units | 12 HE |
| Mounting depth (inside) | 500 mm |
| Total height (external) | 670 mm |
| 19" rack mounting | |
Questions & answers
What is the delivery time of RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U?
The article RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of RCS Audio-Systems WFC-012 U to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U always at the best possible price. We can give you a discount of 2% on RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 3 pieces of RCS Audio-Systems WFC-012 U 19˝-angle Flight-Case 12 U we can offer you a price of 850,44 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
