RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W)

Your rating:
Average rating
product review for RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W)
( 4.6 / 5 ) 23 ratings
RCS Audio-Systems HP-201 R
This image may differ from the desired article.
197,60 EUR
( 235,14 EUR incl. VAT )
≈ £165.19  |  ≈ $218.35
plus delivery charges: 55,00 €
On order · Delivery time approx. 20 workdaysinfo_outline
1x RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W)
Lieske Part No.:101655
Mfg Part No: HP-201 R
UPC/EAN: 4250458262802
Weight:2.9 kg
Type:HP-201R
Graduated prices net
From piecesPrice per pieces
5184,26 EUR
10170,92 EUR
15157,59 EUR
20144,25 EUR

Product information for RCS Audio-Systems HP-201 R:

The HP-201R from RCS Audio-Systems is a toroidal audio transformer for use in 100 V sound systems. It is designed for retrofitting professional speaker cabinets to connect them to existing 100 V networks. With a primary power rating of 200 W and selectable secondary taps for 8, 12, and 16 Ohm, the transformer is suitable for applications requiring high power. The construction allows for precise adaptation to various speaker impedances, ensuring optimal signal transmission.

Applications

The HP-201R is primarily designed for installation in ProSound speaker cabinets to integrate them into existing 100 V systems. It is also suitable for other applications in professional audio and sound reinforcement where stable and powerful signal adaptation is required. The flexible central mounting enables universal installation, even outside speaker enclosures, for example in amplifier or signal distribution systems.

Functions and Equipment in Detail

The transformer features a frequency range of 34 Hz to 27,000 Hz (–3 dB), enabling excellent sound reproduction across the entire audible range, including low frequencies. The 300 mm long, flexible stranded wire connections provide sufficient clearance for various installation scenarios and simplify wiring. The included metal disc and two rubber discs ensure a secure, vibration-damping central mounting, minimizing mechanical vibrations and enhancing stability during operation.

Technology Explained Simply

The toroidal audio transformer uses a closed magnetic core material, ensuring high efficiency and low losses. The efficiency of 90 % means that 90 % of the input power is converted into usable output power, while only 10 % is lost (e.g. as heat). This results in efficient energy conversion and reduces thermal stress. The primary side is rated for 100 V and 200 W, enabling connection to standard 100 V networks. The secondary side offers taps for 8, 12, and 16 Ohm, allowing the transformer to be adapted to different speaker impedances.

Compatibility and Accessories

The HP-201R is specifically designed for use in 100 V sound systems and can be directly connected to corresponding amplifiers or distributors. The specified secondary taps (8, 12, 16 Ohm) allow adaptation to various speaker models. The standards EN 61558, VDE 0570, and IEC 085 ensure compliance with safety and quality standards, guaranteeing reliable and safe operation in professional installations.

Mounting and Installation

Mounting is done via the integrated central mounting with metal disc and rubber discs. This construction allows for easy and stable installation in speaker enclosures or other devices. The 300 mm long stranded wire connections simplify wiring and provide sufficient flexibility for installation in tight or complex spaces.

Advantages in Operation

The HP-201R is characterized by high efficiency and low no-load losses, enhancing operational reliability and energy efficiency. The vibration-damping mounting reduces mechanical noise and ensures quiet operation. The wide frequency response from 34 Hz to 27,000 Hz ensures clear and detailed sound reproduction. Compliance with the standards EN 61558, VDE 0570, and IEC 085 ensures reliability and safety in professional use.

Dimensions and Weight

The transformer has a diameter of 115 mm and a height of 69 mm. The net weight is 2.9 kg. These dimensions and weight are designed for installation in speaker cabinets and allow for compact integration without excessive space consumption.

Technical data
Dimensions (Ø x H)Ø 115 mm, H 69 mm
Frequency range (-3dB)34 - 27.000 Hz
Efficiency90%
Primary (100 V)200 W
Secondary8, 12, 16 Ohm


Questions & answers

What is the delivery time of RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W)?

The article RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W) is currently not in stock but has been backordered.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of RCS Audio-Systems HP-201 R to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W) always at the best possible price. We can give you a discount of 2% on RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W) if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of RCS Audio-Systems HP-201 R 100 V toroidal transformer (200 W) we can offer you a price of 184,26 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
