RCS Audio-Systems CPA-5240C Small central unit, 240 W, 3 U
|
948,10 EUR |
|||||||||||
|
( 1.128,24 EUR incl. VAT ) ≈ £792.61 | ≈ $1,047.65 plus delivery charges: 100,00 € |
|||||||||||
| On order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 685743 | ||||||||||
| Mfg Part No: | CPA-5240C | ||||||||||
| UPC/EAN: | 4250458201610 | ||||||||||
| Weight: | 10 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for RCS Audio-Systems CPA-5240C:
Applications
The small central unit is suitable for professional use in emergency warning systems, building security systems, and public transport facilities. The integrated priority switching ensures that critical messages such as alarms or evacuation orders are transmitted with priority. Remote control of gong and siren, as well as the option to install audio carrier modules, extends its application possibilities in complex communication networks.
Functions and Equipment in Detail
The device features five balanced microphone inputs, with input 1 equipped with a voice-activated priority switching function. Inputs 2 to 4 are switchable between microphone and line input, with phantom power being optionally available for all microphone inputs. AUX inputs 5 to 7 are unbalanced and designed for signals at -10 dB (245 mV). An audio carrier module can be integrated into the designated empty slot to enable, for example, music or information transmission. The special speaking station MS-050P can be connected via a 5-pin screw connector, with a maximum of three speaking stations supported. This speaking station enables activation of pre-alarm and priority functions.
Technology Explained Simply
The output power of 240 W (RMS) enables powerful sound coverage of large rooms or multiple zones. The total harmonic distortion is less than 0.5 %, indicating high signal quality. The frequency range extends from 200 Hz to 19 kHz for microphone inputs and from 35 Hz to 19 kHz for line inputs, ensuring clear and detailed reproduction. Signal-to-noise ratios exceed 70 dB for microphone inputs and 80 dB for line inputs, ensuring clear sound transmission without interference. Bass and treble controls allow individual frequency adjustment of ±10 dB at 100 Hz (bass) and 10 kHz (treble). Power supply is via 230 V AC (50–60 Hz) or 24 V DC, with a maximum current consumption of 3.2 A.
Compatibility and Accessories
The small central unit is equipped with AMP-IN and PRE-OUT sockets, enabling cascading with additional amplifiers or inserting equalizers. The rear panel also features connections for remote control of siren and two-tone gong. Compatible accessories include the microphone table speaking station MS-050P, which connects via the 5-pin screw connector. Integration of audio carrier modules is possible via the empty slot, with exact model designations listed in the datasheet.
Mounting and Installation
The unit is designed for installation in 48,3 cm ( 19 inch ) racks and is supplied with mounting brackets. Dimensions are 430 mm (W) × 133 mm (H) × 352 mm (D). The front panel features controls for the five speaker circuits, master volume, and bass and treble controls. The rear panel includes all connections, including inputs for microphones, AUX, AMP-IN, PRE-OUT, and outputs for 70 V, 100 V, and 8 ohm. Power supply is via a cold appliance power cable and a 24 V DC connection.
Operational Advantages
The combination of high output power, flexible outputs, and integrated priority functions makes the CPA-5240C a reliable core for professional sound systems. Remote control of alarm tones, cascading capability, and integration of audio carrier modules enhance functionality. Clear operation via the front panel and robust construction ensure easy maintenance and long-term operational reliability. Power supply via 230 V AC or 24 V DC offers flexibility during installation, for example in emergency situations with backup power supply.
| Technical data | |
| Outputs, speakers | 70 V or 100 V and low-ohmic 8 Ohm |
| Output power | 240 W (RMS) |
| Signal-to-noise ratio | Mic: > 70 dB Line: > 80 dB |
| Inputs MIC/LINE | Input 2-4 Mic: -50dB (2.45mV) / 2 k Ohm, symmetrical; Line -10dB (245mV), symmetrical |
| Total harmonic distortion | less than 0.5% |
| Height units | 3 HE |
| Power consumption | max. 3.2 A |
| MIC inputs | Input 1 Mic : -50dB (2.45mV) / 2 k Ohm, balanced |
| AMP-IN inputs | AMP IN: 0dB (775mV) 10 k Ohm, unbalanced |
| Dimensions (W x H x D) | 430 x 133 x 352 mm; 3 HE |
| Frequency range | Mic: -3dB (200Hz ~ 19 kHz) Line: -3dB (35Hz ~ 19 kHz) |
| Power supply | 230 V AC (50-60Hz) mains power and 24 V DC |
| Inputs PRE OUT | PRE OUT: 0dB (775mV) 100 Ohm, unbalanced |
| Height and depth adjusters | Bass: ±10dB at 100Hz, Treble: ±10dB at 10 kHz |
| Inputs media player module | Pack Unit: -10dB (245mV) 10 k Ohm, unbalanced |
| AUX inputs | Input 5-7 AUX: -10dB (245mV) / 5 k Ohm, unbalanced |
| 19" rack mounting | |
