RAK Wireless LoRaWAN Enterprise Gateways RAK7289CV2 EU868
|
442,70 EUR |
|
|
( 526,81 EUR incl. VAT ) ≈ £369.21 | ≈ $495.38 plus delivery charges: 100,00 € |
|
| Delivery time from supplier's stock (ca.) 4 workdaysinfo_outline | |
| In Stock: >5 pieces | |
| Lieske Part No.: | 1890418 |
|---|---|
| Mfg Part No: | 715123 |
| Weight: | 5.2 kg |
Product information for RAK Wireless 715123:
The RAK Wireless WisGate Edge Pro Outdoor Gateway, model RAK7289CV2, is an industrial-grade LoRaWAN gateway designed for commercial IoT applications. It features a robust enclosure with IP67 protection rating and complies with NEMA-6 standards, making it suitable for outdoor use. The device is designed for reliable communication in demanding environments and offers integrated power supply options via PoE (802.3af) and 12 V DC. Additionally, it supports connection to solar panels, with the solar kit available as an optional accessory. Power supply is protected by an integrated surge protector.
Applications
This gateway is designed for industrial and commercial applications requiring stable, long-term data transmission over LoRaWAN. Typical use cases include machine monitoring, sensor networks in logistics, smart city applications, or remote infrastructure monitoring. Support for multiple backhaul options — Ethernet, Wi-Fi, and LTE Cat 4 — enables flexible integration into existing network infrastructures. The integrated GPS function supports geographical positioning of the gateway, which is helpful for network planning and monitoring.
Features and Specifications in Detail
The gateway includes two LoRa concentrators supporting a total of 8 channels. The frequency band is fixed at EU868, enabling use in Europe. The reception sensitivity is at least −139 dBm, ensuring high range and sensitivity for LoRa end devices. Maximum transmit power is 27 dBm. The software is based on OpenWRT, offering high adaptability and developer-friendly features. The user interface and operating system WisGateOS 2 enable intuitive control and configuration. The gateway supports LoRaWAN 1.0.3 and provides features such as LoRa frame filtering (node whitelisting), MQTT v3.1 bridging with TLS encryption, and buffering of LoRa frames in packet forwarder mode to prevent data loss during network server (NS) outages. Full-duplex capability is available but not enabled by default.
Technology Explained Simply
The integrated antennas for Wi-Fi, GPS, and LTE are housed within the enclosure, reducing space requirements and simplifying installation. The gateway uses the Semtech SX1303 LoRa chipset, known for stable and powerful LoRa communication. The multi-backhaul feature allows switching between Ethernet, Wi-Fi, and LTE based on network availability, enhancing data transmission reliability. Remote management is performed via the WisDM system, enabling centralized control and monitoring of multiple gateways.
Compatibility and Accessories
The gateway is equipped with a Quectel EG95 module for LTE Cat 4, ensuring high data rates and good network coverage. The Wi-Fi function supports 802.11 b/g/n standards with 2 × 2 MIMO, enabling stable and fast wireless connections. Power supply via PoE or 12 V DC allows flexible installation, even in locations without direct power access. The solar kit is available as an optional accessory, expanding deployment possibilities in remote or solar-powered locations.
Mounting and Installation
The gateway comes with mounting brackets, a set of screws, and an Ethernet gland, enabling secure and weatherproof installation on exterior walls or poles. The PoE injector is also included and provides power supply through the network cable. Installation is performed via the integrated user interface, enabling quick and easy setup. Cable glands in the enclosure ensure a tight and waterproof connection for attached cables.
Operational Advantages
The combination of a robust enclosure, multiple backhaul options, and support for LoRaWAN 1.0.3 makes this gateway a reliable solution for IoT applications. Buffering of LoRa frames during network server outages prevents data loss. The OpenWRT-based software allows development of custom applications via the open SDK. Remote management via WisDM simplifies monitoring and maintenance of multiple gateways from a distance. Integrated antennas for Wi-Fi, GPS, and LTE reduce the number of external components and simplify installation.
The gateway is designed for outdoor use and offers high reliability thanks to its IP67 protection rating. Support for solar power supply expands deployment options in remote or off-grid locations. The combination of industrial quality and flexible configuration makes it a suitable solution for demanding IoT applications.
Applications
This gateway is designed for industrial and commercial applications requiring stable, long-term data transmission over LoRaWAN. Typical use cases include machine monitoring, sensor networks in logistics, smart city applications, or remote infrastructure monitoring. Support for multiple backhaul options — Ethernet, Wi-Fi, and LTE Cat 4 — enables flexible integration into existing network infrastructures. The integrated GPS function supports geographical positioning of the gateway, which is helpful for network planning and monitoring.
Features and Specifications in Detail
The gateway includes two LoRa concentrators supporting a total of 8 channels. The frequency band is fixed at EU868, enabling use in Europe. The reception sensitivity is at least −139 dBm, ensuring high range and sensitivity for LoRa end devices. Maximum transmit power is 27 dBm. The software is based on OpenWRT, offering high adaptability and developer-friendly features. The user interface and operating system WisGateOS 2 enable intuitive control and configuration. The gateway supports LoRaWAN 1.0.3 and provides features such as LoRa frame filtering (node whitelisting), MQTT v3.1 bridging with TLS encryption, and buffering of LoRa frames in packet forwarder mode to prevent data loss during network server (NS) outages. Full-duplex capability is available but not enabled by default.
Technology Explained Simply
The integrated antennas for Wi-Fi, GPS, and LTE are housed within the enclosure, reducing space requirements and simplifying installation. The gateway uses the Semtech SX1303 LoRa chipset, known for stable and powerful LoRa communication. The multi-backhaul feature allows switching between Ethernet, Wi-Fi, and LTE based on network availability, enhancing data transmission reliability. Remote management is performed via the WisDM system, enabling centralized control and monitoring of multiple gateways.
Compatibility and Accessories
The gateway is equipped with a Quectel EG95 module for LTE Cat 4, ensuring high data rates and good network coverage. The Wi-Fi function supports 802.11 b/g/n standards with 2 × 2 MIMO, enabling stable and fast wireless connections. Power supply via PoE or 12 V DC allows flexible installation, even in locations without direct power access. The solar kit is available as an optional accessory, expanding deployment possibilities in remote or solar-powered locations.
Mounting and Installation
The gateway comes with mounting brackets, a set of screws, and an Ethernet gland, enabling secure and weatherproof installation on exterior walls or poles. The PoE injector is also included and provides power supply through the network cable. Installation is performed via the integrated user interface, enabling quick and easy setup. Cable glands in the enclosure ensure a tight and waterproof connection for attached cables.
Operational Advantages
The combination of a robust enclosure, multiple backhaul options, and support for LoRaWAN 1.0.3 makes this gateway a reliable solution for IoT applications. Buffering of LoRa frames during network server outages prevents data loss. The OpenWRT-based software allows development of custom applications via the open SDK. Remote management via WisDM simplifies monitoring and maintenance of multiple gateways from a distance. Integrated antennas for Wi-Fi, GPS, and LTE reduce the number of external components and simplify installation.
The gateway is designed for outdoor use and offers high reliability thanks to its IP67 protection rating. Support for solar power supply expands deployment options in remote or off-grid locations. The combination of industrial quality and flexible configuration makes it a suitable solution for demanding IoT applications.
| General | |
| Degree of protection | IP67 |
| NEMA protection class | 6 |
| LoRa channels | 8 |
| Frequency band | EU868 |
| Mobile phone standard | LTE Cat 4 |
| Backhaul options | Ethernet, Wi-Fi, LTE |
| Wi-Fi standard | 802.11 b/g/n |
| Wi-Fi MIMO | 2 × 2 |
| GPS (global positioning system) | Integrated |
| Over voltage protection | Integrated |
| Reception sensitivity | −139 dBm |
| Transmitting power | 27 dBm |
| LoRaWAN version | 1.0.3 |
| Frame filtering | Node whitelisting |
| MQTT version | 3.1 |
| Full-duplex | Optional |
| Remote management | WisDM |
| Solar power supply | Optional |
| TLS encryption | |
