RAK Wireless LoRa WisGate Edge Prime Gateway RAK7240-0X-14X 8 Ch / LTE

RAK Wireless WisGate Edge Prime Gateway
RAK7240-0X-14X 8Ch / LTE
Overview
The WisGate Edge Prime (RAK7240) is an ideal product for large-scale LPWAN deployments where cost efficiency and performance are critical. The wide range of customization options allows flexibility in delivering a solution. You can even have your own logo printed on the case for a small fee!
Previously, logo customization for this product was only possible with a minimum order quantity (MOQ) of 100 pieces. We have received many inquiries as to whether logo customization is also possible for smaller quantities. For this reason we have reduced the minimum order quantity to just 10 pieces!
The RAK7240 gives you a solid, out-of-the-box experience for rapid IoT adoption. Since the software and user interface are based on OpenWRT, it is perfect for developing your own applications using an open SDK.
Using the RAK7240 for roll-out projects is advantageous as it can serve up to 128 nodes (license included) and operates in license-free sub-gigahertz frequency bands such as 433 MHz, 868 MHz (Europe), 915 MHz (Australia and North America) and 923 MHz (Asia).
Features
Hardware Features Industrial-grade IP65 housing with cable glands PoE + surge protection Two LoRa® concentrators for up to 16 channels Backhaul: Wi-Fi, LTE and Ethernet GPS SD card slot Software features Integrated LoRa® server (license for up to 128 LoRa ® nodes included in delivery (higher levels are subject to a charge) OpenVPN software and UI are based on OpenWRT LoRaWAN® 1.0.2 LoRa® frame filtering (node whitelisting) MQTT v3.1 bridging with TLS encryption Buffering of LoRa® frames in the event of a NS failure (no data loss) Scope of delivery1 x 8-channel device with LTE module 2 x LTE antenna 1 x GPS antenna 1 x 2.4G Wi-Fi antenna 1 x PoE injector 1 x mounting kit 1 x manual! ! LoRa antennas not included!! Link to data sheet
