Mitsubishi 129617 Q68ADI analog input module 8 inputs current

Your rating:
Average rating
product review for Mitsubishi 129617 Q68ADI analog input module 8 inputs current
( 4.5 / 5 ) 20 ratings
Mitsubishi 129617
This image may differ from the desired article.
Mitsubishi 129617Mitsubishi 129617
749,20 EUR 781,78 EUR
( 891,55 EUR incl. VAT )
≈ £627.08  |  ≈ $823.37
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Mitsubishi 129617 Q68ADI analog input module 8 inputs current
Lieske Part No.:543632
Mfg Part No: 129617
Weight:0.24 kg
Type:Q68ADI

Product information for Mitsubishi 129617:

The Mitsubishi Q68ADI is an analog input module for the SPS-SystemQ, designed for the acquisition of 8 analog input signals in the current range. It serves the integration of analog sensor data into industrial control systems, particularly in applications where current signals are used as measurement values, such as in process automation or machine parameter monitoring. The module is part of a modular SPS system and is mounted in a standard enclosure or control console to enable real-time data processing.

Applications

The Q68ADI is used in industrial environments where continuous measurement values from sensors, such as current values from load cells, temperature sensors, or other current-output devices, must be read into the control system. It is suitable for installations in the manufacturing industry, energy supply, or process engineering, where high reliability and precision of measurement values are required. The modular architecture allows flexible expansion of the control unit without fundamental changes to the system design.

Functions and Equipment in Detail

The module features 8 independent analog inputs, each designed for the acquisition of current signals. The signals are digitized and transmitted to the central SPS control, where they are processed for control logic. The inputs are designed to be compatible with common current sensors, such as those providing 4–20 mA or similar current ranges. Digital signal processing occurs within the module, ensuring precise reproduction of analog values.

Technology Explained Simply

The analog inputs of the Q68ADI are designed for direct connection to current signal sources. The signals are converted into digital values via an internal analog-to-digital converter and then transmitted to the main control via the SPS bus connection. Current measurement occurs within a defined range suitable for the respective application. The modular architecture ensures high signal quality and minimizes interference from electrical noise, which is critical for reliability in industrial environments.

Compatibility and Accessories

The Q68ADI is specifically developed for the Mitsubishi SPS-SystemQ and can only be operated in conjunction with compatible SPS controls and buses. It is part of a modular system consisting of various input and output modules that can be combined according to requirements. Connections are made via standardized interfaces designed for the SystemQ.

Mounting and Installation

The module is mounted in a standard enclosure or control console, using the designated mounting elements. The connection terminals are designed for direct connection to sensors. Installation follows the guidelines in the Mitsubishi system documentation, ensuring correct assignment of inputs and secure electrical connections. Module positioning typically occurs within an enclosure providing the required protection against environmental influences.

Advantages in Operation

Using the Q68ADI enables precise and reliable acquisition of analog current signals in industrial plants. The modular design offers flexibility for system expansion, and integration into the SPS-SystemQ ensures high compatibility with existing control components. Digital signal processing ensures low susceptibility to interference and high accuracy of measurement values, which is crucial for the quality of control logic. Operational safety is supported by the robust construction and the reliability of Mitsubishi technology.

General
Number of inputs8
Input typeCurrent
ManufacturerMitsubishi
Module typeAnalogue input module


Questions & answers

What is the delivery time of Mitsubishi 129617 Q68ADI analog input module 8 inputs current ?

The article Mitsubishi 129617 Q68ADI analog input module 8 inputs current is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Mitsubishi 129617 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Mitsubishi 129617 Q68ADI analog input module 8 inputs current always at the best possible price. We can give you a discount of 2% on Mitsubishi 129617 Q68ADI analog input module 8 inputs current if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
