Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw

Your rating:
Average rating
product review for Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw
( 4.7 / 5 ) 36 ratings
Mitsubishi 127588
This image may differ from the desired article.
Mitsubishi 127588Mitsubishi 127588
307,40 EUR 313,10 EUR
( 365,81 EUR incl. VAT )
≈ £257.29  |  ≈ $337.83
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw
Lieske Part No.:147752
Mfg Part No: 127588
Weight:0.17 kg
Type:QY80

Product information for Mitsubishi 127588:

The Mitsubishi QY80 is an output module for the SPS-SystemQ, specifically designed for controlling external loads in industrial automation environments. It features 16 transistor outputs rated for an operating voltage of 12/24 V DC, each capable of delivering a maximum current of 0.5 A. Connections are made via screw terminals, ensuring a secure and mechanically stable connection. The module serves as an interface between the control logic of the SPS and connected consumers, such as relays, valves, or small electric motors.

Applications

The QY80 output module is intended for use in industrial control systems, particularly in plants requiring high reliability and clear separation between control and load. It is suitable for applications in manufacturing automation, packaging technology, or machine control, where digital signals from the SPS must be converted into electrical impulses for external devices. The use of transistor outputs enables fast switching speed and low switching delay, which is advantageous for time-critical processes.

Functions and Equipment in Detail

The module provides 16 independent transistor outputs, each capable of handling a maximum load of 0.5 A at 12 or 24 V DC. The screw terminals allow for simple and secure connection of wires, with the mechanical strength of the connection ensured by the screw connection. The outputs are designed for operation with loads that do not exhibit high inductance, as transistor outputs are sensitive to inductive kickback. Control is performed via the SPS control system, with the module converting digital signals into corresponding electrical signals for the loads.

Technology Explained Simply

Transistor outputs function as electronic switches, activated or deactivated by a control signal from the SPS. Unlike relay outputs, which use mechanical contacts, transistor outputs offer higher switching speed and longer service life, as they contain no moving parts. The operating voltage of 12/24 V DC is a standard in automation technology, as these voltages are widely used in many industrial systems. The maximum current of 0.5 A per output is sufficient for many small consumers, such as signal lights, small electric motors, or relays powered by an external power supply.

Compatibility and Accessories

The QY80 is specifically developed for the Mitsubishi SPS-SystemQ and can be integrated as an output module within this system. It is compatible with the corresponding SPS control units and rack systems in the SystemQ portfolio. The use of screw terminals allows for easy integration into existing installations, with cable connections made directly to the terminals.

Mounting and Installation

The QY80 is mounted into the appropriate SPS rack of the SystemQ, where module slots are provided. Mechanical fixation is achieved via plug-in connection, with electrical connection established through internal contacts of the rack. The load connection wires are attached to the screw terminals, with polarity (positive/negative) to be observed according to load requirements. Installation requires no additional tools other than a screwdriver for securing the wires to the terminals.

Advantages in Operation

Using the QY80 provides high operational reliability due to the robust screw terminal technology and the electronic switching function of the transistors. The low switching delay enables precise control of processes, and the long service life of the transistors reduces maintenance requirements. Compatibility with the Mitsubishi SystemQ ensures seamless integration into existing control systems, simplifying system expansion and maintenance. The clear separation between control and load increases safety and clarity of the installation.

General
ManufacturerMitsubishi
Number of outputs16
Output typeTransistor
Operating voltage12/24 V DC
Maximum output current0,5 A
Connection typeScrew terminals
System compatibilitySPS SystemQ


Questions & answers

What is the delivery time of Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw ?

The article Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Mitsubishi 127588 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw always at the best possible price. We can give you a discount of 2% on Mitsubishi 127588 QY80 output module 12/24 VDC 0.5 A 16 trans. screw if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
