MICROSENS MS140040UP3 M45 mounting kit for recessed installation 4-piece set: 3-way recessed outlet, device carrier, cover frame, blank module, RAL9010 content_copy

The M45 mounting kit for flush installation by MICROSENS is a 4-piece set specifically developed for integrating network modules into flush installations. The set includes a 3-way flush box, a device carrier, a cover frame, and a blank module, all in the colour RAL9010. It serves as a mounting aid for M45 network modules, which are standardised in the M45 module technology with dimensions of 45x45 mm. These modules enable space-saving and quick snap-in mounting in existing installations, thereby making cabling in offices, industrial facilities or other premises more efficient.

Applications
The mounting kit is intended for flush installations in walls or hollow walls, where network connections are to be integrated into the wall cladding. It is part of a comprehensive accessory range for MICROSENS installation components and supports various mounting scenarios, including integration into device installation channels from various manufacturers such as Hager, OBO Bettermann or Rehau. Use in underfloor systems or in furniture installations such as recessed table columns is also mentioned in the product environment, but not explicitly specified for this item.

Functions and Equipment in Detail
The set consists of four components that together form a stable and visually uniform installation solution. The 3-way flush box provides space for three M45 modules, enabling multiple network connections at one location. The device carrier serves as a mounting element for the modules and ensures secure anchoring in the flush channel. The cover frame completes the installation visually and matches the wall cladding. The blank module is used to visually close empty module slots, ensuring a uniform appearance.

Technology Explained Simply
The M45 module technology is based on a standard format of 45x45 mm, commonly used for network modules in IT infrastructure. The snap-in mounting allows for quick and tool-free installation, accelerating the setup of network connections. The colour RAL9010 is a neutral white tone that blends into most interior designs.

Compatibility and Accessories
The mounting kit is specifically designed for M45 network modules used in the M45 module technology. It is part of a comprehensive accessory range that also includes solutions for PoE+ power supplies in underfloor and wall installations. Use in conjunction with device installation channels from various manufacturers is mentioned in the product environment, but not explicitly confirmed for this item. Compatibility with other MICROSENS products such as locking adapters for Micro Switches is described in the general product environment, but not directly specified for this mounting kit.

Installation and Mounting
Installation is carried out in flush installations, with the 3-way flush box inserted into the pre-fabricated channel. The device carrier is inserted into the box, followed by the desired M45 modules. The cover frame is then placed over the box to complete the installation visually. The blank module is inserted into empty module slots to ensure a uniform appearance.

Operational Advantages
The mounting kit enables clean and structured integration of network connections into flush installations. The use of M45 modules offers flexibility in choosing the connection type, such as Ethernet, PoE or other protocols. The 3-way configuration allows multiple connections to be placed at one location, simplifying the planning of network infrastructures. The visual uniformity provided by the cover frame and blank module ensures a professional appearance that fits into various interior designs.

General
Module technology	M45

---
