Metrix HX0080 USB/SD adapter + Micro-SD card content_copy

The MTX 1050 from Metrix is a compact spectrum analyser designed specifically for EMC pre-compliance testing. As a blind device without an integrated display, it is connected directly via USB to a PC, making it space-saving and mobile. The measurement results are displayed in colour and high resolution on the PC screen, with horizontal resolution reaching up to 5,000 points. This enables detailed analysis and precise representation of frequency distribution. The software for operation runs under Windows and supports functions such as report generation, screen captures, and export of measurement data to Excel files.

Applications
The MTX 1050 is primarily designed for EMC pre-compliance testing, i.e. for preliminary testing of devices for electromagnetic compatibility before formal certifications are carried out. It is particularly suitable for small and medium-sized enterprises (SMEs) requiring a cost-effective solution for frequency analysis, as well as for use in technical education at engineering and vocational schools. The combination of compact design and direct PC connection makes it suitable for both laboratory applications and mobile field scenarios.

Functions and Equipment in Detail
The analyser offers a frequency range from 400 kHz to 1 GHz, making it suitable for a wide range of measurement tasks in the field of high-frequency technology. Frequency stability is ±5 ppm per year, ensuring high measurement accuracy over extended periods. The dynamic range extends from -90 dBm to +20 dBm, enabling both weak and strong signals to be captured. The integrated FM demodulation allows analysis of modulated signals. With 6 sampling speeds, 3 analysis filters, and 3 video filters, the analyser can be flexibly adapted to different measurement requirements. Up to four simultaneous measurements (Peak-Auto, Marker, 2 Difference Cursors) are possible, increasing efficiency in data acquisition.

Technology Explained Simply
The MTX 1050 operates as an external measuring device connected via USB to a PC. Control is performed using a special Windows software, which is quickly and easily installed via a “Plug & Play” connection. The software allows storage of countless configurations with plain text naming, facilitating reuse of settings for recurring measurement tasks. The measurement results are displayed in high resolution on the PC screen, with horizontal resolution up to 5,000 points. This ensures detailed visualisation of frequency spectra.

Compatibility and Accessories
The MTX 1050 can be used in combination with near-field probes such as models HX0082 and HX0083. These probes enable Q-peak detection, simplifying the execution of EMC pre-compliance tests. The probes are used for local detection of electromagnetic fields and are directly connected to the analyser to optimise measurement results. The software supports data export to Excel, facilitating further processing and documentation of results.

Installation and Mounting
Installation is performed via a USB connection to the PC. The software is designed for Windows systems and is automatically recognised and installed via the “Plug & Play” mode. No additional drivers or tools are required. Operation is performed via the software interface, which is available in multiple languages. Setup is therefore quick and can be done without special technical knowledge.

Operational Advantages
The MTX 1050 offers a combination of compactness, flexibility, and precise measurement. The direct connection to the PC enables fast data processing and display. Support for report generation and data export to Excel makes it particularly suitable for applications requiring documentation. High frequency stability and wide dynamic range ensure reliable results. The ability to perform multiple measurements simultaneously increases efficiency when analysing complex signals. Use with near-field probes extends functionality for specific EMC applications.

General
Sampling speeds	6
Analysis filter	3
Video filter	3

---
