LevelOne XEL-1291 Switch 8x10GE/4x10GSFP+ 48,3 cm ( 19 inch ) Managed L3
|
754,20 EUR |
|
|
( 897,50 EUR incl. VAT ) ≈ £635.04 | ≈ $846.97 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >25 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 155144 |
| Mfg Part No: | XEL-1291 |
| UPC/EAN: | 4015867242988 |
| Weight: | 3.439 kg |
| Data transmission | |
| Switching capacity | 240 Gbit/s |
| Forwarding rate | 178.56 Mpps |
| Jumbo frames | 12000 |
| Static route | |
| Jumbo frames support | |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | |
| LED indicators | |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 8517620000 |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | |
| Web-based management | |
| System event log | |
| Multicast features | |
| Multicast Listener Discovery (MLD) snooping | Y |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3bz, IEEE 802.3z |
| 10G support | |
| Full duplex | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Spanning tree protocol | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Optical fiber | |
| Maximum transfer distance (Multi-mode) | 16 m |
| Packaging content | |
| Cables included | AC |
| Quick start guide | |
| Rack mount kit | |
| Packaging data | |
| Package type | Box |
| Package width | 495 mm |
| Package depth | 315 mm |
| Package height | 72 mm |
| Package weight | 3.61 kg |
| Performance | |
| Mean time between failures (MTBF) | 100000 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45 |
| Power connector | AC-in jack |
| Power | |
| Power source | DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 2 A |
| Power consumption (max) | 48.2 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Security | |
| DHCP features | DHCP relay, DHCP snooping, DHCP Option 82, DHCP Option 43, DHCP Option 60, DHCP Option 61, DHCP Option 67, DHCP client |
| IGMP snooping | |
| IGMP proxy | |
| Technical details | |
| Shipping (inner) case height | 34.5 cm |
| Shipping (inner) case width | 50.9 cm |
| Shipping (inner) case length | 38.9 cm |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case gross weight | 19 kg |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 207 mm |
| Height | 44 mm |
| Weight | 2.5 kg |
Questions & answers
What is the delivery time of LevelOne XEL-1291 Switch 8x10GE/4x10GSFP+ 48,3 cm ( 19 inch ) Managed L3?
The article LevelOne XEL-1291 Switch 8x10GE/4x10GSFP+ 48,3 cm ( 19 inch ) Managed L3 is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of LevelOne XEL-1291 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you LevelOne XEL-1291 Switch 8x10GE/4x10GSFP+ 48,3 cm ( 19 inch ) Managed L3 always at the best possible price. We can give you a discount of 2% on LevelOne XEL-1291 Switch 8x10GE/4x10GSFP+ 48,3 cm ( 19 inch ) Managed L3 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
