LevelOne SFP Transceiver 1.25G Multi-mode Duplex LC 550m
|
19,49 EUR |
|
|
( 23,19 EUR incl. VAT ) ≈ £16.31 | ≈ $21.81 plus delivery charges: 55,00 € |
|
| On order · Expected to be available from 15.12.2026info_outline | |
| End-Of-Life: | 15. Aug 2025 |
|---|---|
| Lieske Part No.: | 927496 |
| Mfg Part No: | SFP-3001 |
| UPC/EAN: | 4015867154663 |
| Weight: | 0.02 kg |
| Certificates | |
| Compliance certificates | RoHS |
| Safety | EN 60825-1 |
| Certification | CE, FCC |
| Features | |
| Plug and Play | |
| Hot-swap | |
| Logistics data | |
| Harmonized System (HS) code | 85369010 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package width | 106 mm |
| Package depth | 20 mm |
| Package height | 65 mm |
| Package weight | 35 g |
| Performance | |
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Tx power (min) | -9.5 dBmW |
| Tx power (max) | -3 dBmW |
| Networking standards | IEEE 802.3z |
| Duplex system | Full |
| Fiber ports quantity | 1 |
| Single-mode fiber (SMF) supported | |
| Multi-mode fiber (MMF) supported | |
| Power | |
| Input voltage | 3.3 V |
| Maximum voltage | 6 V |
| Maximum current | 0.3 A |
| Weight & dimensions | |
| Width | 57 mm |
| Depth | 12 mm |
| Height | 13.7 mm |
| Weight | 20 g |
Questions & answers
What is the delivery time of LevelOne SFP Transceiver 1.25G Multi-mode Duplex LC 550m?
The article LevelOne SFP Transceiver 1.25G Multi-mode Duplex LC 550m is currently not in stock but has been backordered.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of LevelOne SFP-3001 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you LevelOne SFP Transceiver 1.25G Multi-mode Duplex LC 550m always at the best possible price. We can give you a discount of 2% on LevelOne SFP Transceiver 1.25G Multi-mode Duplex LC 550m if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
